e. The blue light flashes 3 times at the end of the cleaning cycle, the pool cleaner
systematically approaches the poolside after about 2 minutes of operation, then the pool
cleaner stops while the light lights up blue.
f.
Status
Ongoing operating
Completed cycle
Out of order
g. Turn the switch knob to OFF, the light goes out. Please clean the filter and retention tank
after each use..
3.0 MAINTENANCE AND ADJUSTMENT OF POOL CLEANERS
3.1 Function and adjustment of nozzles
There are two nozzles on the pool cleaner. While one opens, the other closes. The water is
expelled through the open nozzle and propels the pool cleaner in the opposite direction. Adjust
the orientation of the nozzles using the markers to make the pool cleaner describe a trajectory
following a slight curve.
a. Adjustment of nozzles and trajectories
generality：Nozzle angle markers from 0 ° to 40 °
Set the nozzles to 0°，the unit operates in a straight line.
Position the nozzles at 0° to 40° to obtain an increasingly large curve.
b. Example of nozzle positions
Example 1: Default setting: 0°--20°, for most pools
www.colibriproducts.ch | Industriestrasse | CH-5728 Gontenschwil
ON
Cleaner light
blue light flashes
Permanent bleu light
Bleu light flashes quickly
OFF
