3.1.1 Main Controller (BA160510)
1) Front
Display Rotation button Program button Memory button
Speed Up/Down button Torque Up/Down button
3.1.2 Foot switch (BA160535)
Hanger hole
Coolant button
Operation button
Gear ratio button
Coolant button
Water injection
pipe fixture
Motor connection
Optic LED button
Foot switch connector
Foot switch coable
Rotation button
Program button
4
2) Rear
Power cable terminal
Fuse box Power switch
3.1.3 Motor (BA160530)
Handpiece connection
Connection for irrgation hanger
Groove on
irrigation hanger
Foot switch terminal
Motor connection
Optic LED
