optrel 4441.900 Bedienungsanleitung Seite 2

suppliedair description
Pressure gauge
Noise silencer
Hose connector
Whistle
Airflow regulation
(reducing valve)
Pressure hose conn.
Airflow adjustment - suppliedair
1 2
3 4
suppliedair Conditioner assembly Mounting on the wall
If you want to put the Conditioner
filter station safely on the wall, include
the wall mount when assembling
the filter station. In order to reach
sufficient firmness, use adequate
dowels and screws, depending on
the wall material.
In order to maximise the firmness, use screws with
shank width of 8 mm. The diameter of the head has
to be smaller than 17 mm.
suppliedair Conditioner filter change
1 2 3
4 5 6
