L5QA2/XE, XE2, L7QA2/XE, XE2 GB 2002, 7, 25
SPECIFICATIONS
TV format
: Compatible with PAL TV format
Scanning system
: 625 TV lines, 50 fields/sec., 2:1 interlaced
Capturing element
: Interline transmission method, 1/3 inch CCD
fixed capturing element
Effective picture element : 440 K (VDC-C1572FP, VDC-C2572FP)
290 K (VDC-B1512FP, VDC-B2512FP)
Synchronization system
: Internal sync
Horizontal resolution
: 460 TV lines (VDC-C1572FP, VDC-C2572FP)
380 TV lines (VDC-B1512FP, VDC-B2512FP)
: 1.0 Vp-p/75 Ω (BNC termination)
Video output level
Video S/N ratio
: 50 dB (VDC-B1512FP, VDC-B2512FP)
48 dB (VDC-C1572FP, VDC-C2572FP)
Minimum required
: 0.6 Lux (50IRE) (VDC-B1512FP, VDC-B2512FP)
illumination
0.4 Lux (30IRE) (VDC-B1512FP, VDC-B2512FP)
3.6 Lux (50IRE) (VDC-C1572FP, VDC-C2572FP)
1.8 Lux (30IRE) (VDC-C1572FP, VDC-C2572FP)
White balance (colour only) : Indoor/outdoor/push lock selectable manually
Backlight compensation
: ON/OFF selectable manually, center focus
(BLC) function
separate photometry method
B/W cameras: ON only
Backlight compensation
: Manual V. R.
iris level adjustment
Flickerless function
: ON/OFF selectable manually
B/W cameras: None
Gain control
: ON/OFF selectable manually
B/W cameras: None
Built-in lens
: Fixed lens F2.0, f= 4 mm
: Horizontal (pan) → 360° , Vertical (tilt) → 80°
Manual angle of field
adjustment function
Operating environment
: Temperature –10° C – +50° C
Humidity 90% RH or less
Storage environment
: Temperature –20° C – +60° C
Humidity 95% RH or less
Power voltage/
: 12 V DC
Power consumption
1.5 W (VDC-B1512FP, VDC-B2512FP)
(Approx.)
2.6 W (VDC-C1572FP, VDC-C2572FP)
Weight (Approx.)
: 1.3 kg (VDC-C1572FP, VDC-B1512FP)
0.7 kg (VDC-C2572FP, VDC-B2512FP)
: 139.7 (W) x 94.5 (H) mm, Dome 79.4 mm φ
Dimensions
Features and specifications are subject to change without
prior notice or obligations.
Approvals: IP66/CE
This camera has been certified to IP66 standards when
properly installed.
Use only an IP66 certified enclosure or an electrical box.
Ensure all openings in enclosure are sealed as per
manufacturer's instructions.
6
English
