BALTENSWEILER
LET S
MOUNTING AND OPERATING INSTRUCTIONS
IMPORTANT! Read the instructions carefully beforehand and keep for future reference.
!
For safety regulations, protection classes and instructions, see page 5.

Mounting instructions

Do not connect the luminaire to the power supply until
it is fully mounted and placed.
Remove the protective cap from the rod.
1
Press the rod into the ball joint as far as possible
2
fixate the grub screw with the allen key
Rod
Protective cap
The ball joint can be readjusted here.
3
Mounting of the luminaire head:
4
When assembling the rod with the luminaire head,
place hole on hole
A
Gently screw in the M3 grub screw.
C
4
Magnetic contact
Small allen key
Magnet must be attached to the rod.
5
Once the luminaire is fully mounted and placed,
it may be connected to the power supply.

Package contents:

- Base, Rod, Luminaire head
- Mounting material (Allen key)
LICHT UND LEUCHTEN
.
2b
2a
Limit stop
1
2b
3
Base with cover
.
B
Luminaire head
A
B
Rod
C
A
www.baltensweiler.ch
and
2a
3
B
C
info@baltensweiler.ch Tel. +41 41 429 00 30
Do not tighten/loosen these screws!
(Adjusted by the manufaturer)
5
Cable depot in the base
M 1127/16090/SaWa/25.05.2021
Luminaire head
Rod
EN
3 / 5
