1.2. Compressed air connection

For this, the compressed air
hose that is included in the
scope of delivery is plugged into the compressed air outlet located
on the back. The connection is airtight
immediately upon connection.
If the air hose is to be removed again,
the small simultanously pulled out. The
other end of the compressed air hose is
connected to the compressed air supply
(either compressed air bottle or building
supply). The air pressure can be
between 2.5 bar and 7.5 bar.
Funke-Dr.N.Gerber Labortechnik GmbH
2. Use of the RD-8

2.1 Temperature setting

Thedesired
(desired value) can be set
by follows:
2.1.1. Press the "P" button
A desired
value appears
display.
2.1.2. The
desired temperature can be
reduced or increased with
the " " or " " buttons.
The setting is automatically
accepted after 2 seconds.
2.1.3. If no further adjustment takes place, the controller returns to
normal display after approx. 30 seconds. This means that the
respective actual temperature is displayed again. The last displaed
desired temperature value is saved.
All settings are saved and are maintained even if the device is
switched off or the network cable is unpugged.
You can find addional setting possibilities in the extensive operating
instructions for the Jumo temerature controller.
