UNILITE L-1000 Kurzanleitung

FEATURES
• Super bright 1000 lumen 6500k spot beam LED
• With additional 750 lumen 6500k COB LED floodlight
• Super tough polycarbonate, ABS and aluminium construction
• Glow-in-the-Dark strip around reflector for extra visibility
• Easy press dual switches for easy mode selection
• Convenient shoulder carry strap included
• Threaded hole in the base for attaching to a tripod
• IPX6 Water proof
• High power 3.7v 8000mAh li-ion battery
• 2A USB power bank for charging devices
• Battery level and charging indicators
• Faster 2A USB-C charging - 4½ hour charge time
• 1m USB-C charging cable included
BATTERY - 3.7v 8000mAh Li-ion Rechargeable Battery
WEIGHT - 730g
DIMENSIONS - 108 x 200 x 131mm
ADVICE & IMPORTANT INFORMATION!
LEDs will become hot when switched on; do not touch and never place face down on any
surface – risk of fire! Even once the lamp has been switched off, DO NOT place face down as
the LEDs will stay hot/warm for a while.
Do not look directly at the LED. Do not operate in direct sunlight or extreme temperature
conditions (below -20⁰C or above 60⁰C).
Do not use the device if there is any visible damage to the housing, charge port, switches or
cable. Take care when using a USB plug adaptor, check for any damage. DO NOT exceed 5V 2A
charging output or damage may occur to the battery.
The rechargeable battery will reach full performance after a few complete charging and
discharging cycles.
To keep the rechargeable battery in optimum condition, it should be recharged every 3-6
months, especially if it is not being used for a long period of time. Always fully charge batteries
before storage.
Always protect lithium batteries from heat, intense sunlight, fire, water and moisture – danger
of explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation
and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation persists, seek
medical advice. Seek immediate medical assistance if lithium battery fluid comes into contact
with the eyes.
Children under 12 years of age should only use the product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and
can be dangerous. Improper use or modification is not covered under the warranty.
Take care not to let the lenses come into contact with hard/sharp objects, damage/scratches
to the lenses will affect light output.
This product is water resistant to IPX6. If the product has been subjected to excessive water
the warranty may be void.
This product has a 1 year standard warranty (or extended to 2 years once registered online
at WWW.UNILITE.CO.UK) against manufacturing faults and defects. It does not cover normal
wear and tear, modifications, accidental damage or poor maintenance. Unilite warranties do
not cover battery leaks or the use of incorrect chargers and cables that can damage batteries.
Do not dispose of this device in normal household waste. It must be disposed of via an
authorised electrical appliance disposal centre or at your local waste disposal unit.
Please re-use or recycle packaging where possible.
Keep these instructions for future reference or for subsequent possessors.
www.unilite.co.uk
ANSI FL 1 Standard
SPOT BEAM - HIGH
SPOT BEAM - MID
SPOT BEAM - LOW
FLOOD LIGHT - HIGH
FLOOD LIGHT - LOW
OPERATION
TOP SWITCH: Spot Beam Mode
Switch Sequence: HIGH > MEDIUM >
LOW > OFF.
[If left in any setting for over 3 seconds, the
next press will turn the lamp off]
BOTTOM SWITCH: Floodlight Mode
Switch Sequence: HIGH > LOW > OFF.
[If left in any setting for over 3 seconds, the
next press will turn the lamp off]
CHARGING
1. Only use a 5V USB-C cable (max 2A).
2. Lift the charging port cover on the end of the lamp.
3. Plug the USB-C end of the cable into the charge port.
4. Plug the USB end of the cable into a USB charging port (do not
exceed 5V 2A output or damage may occur).
5. Charge Time: 4½ hours
(PRODUCT CAN BE USED WHILE RECHARGING)
The lamp can also be used as a 2A Power Bank, plug the USB end of your
device charging cable into the USB port.
**Warranty void if not used with specified chargers**
Power indicator
Recharging indicator
Charging & Power
Indicators
L-1000
1000
532 M
Lumens
500
386 M
Lumens
190
248 M
Lumens
750
28 M
Lumens
275
19 M
Lumens
Charging Port
75%-100%
50%-75% & Power Bank
25%-50%
5%-25%
<5%
<25%
25%-50%
50%-75%
75%-100%
100%
7 H
11 H
28 H
6 H
16 H
