2.4 Expansion Slots (PCI Express Slot)
There is 1 PCI Express slot slot on the motherboard.
Before installing an expansion card, please make sure that the power supply is
switched off or the power cord is unplugged. Please read the documentation of the
expansion card and make necessary hardware settings for the card before you start
the installation.
PCIe slots:
th TM
11 Gen Intel® Core Processors:
PCIE1 (PCIe 4.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
10 th Gen Intel® Core TM Processors:
PCIE1 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
* Supports PCIe riser cards to extend one x16 slot to two x8 slots
