Storage
Connector
12
• 3 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology
18), NCQ, AHCI and Hot Plug
• 1 x Hyper M.2 Socket (M2_2), supports M Key type 2280
M.2 PCI Express module up to Gen4x4 (64 Gb/s) (Only sup-
th
ported with 11 Gen Intel® Core
• 1 x Ultra M.2 Socket (M2_1), supports M Key type 2280 M.2
SATA3 6.0 Gb/s module and M.2 PCI Express module up to
Gen3 x4 (32 Gb/s)*
* Supports Intel® Optane
* Supports NVMe SSD as boot disks
• 1 x Chassis Intrusion and Speaker Header
• 1 x RGB LED Header
* Support in total up to 12V/3A, 36W LED Strip
• 1 x Addressable LED Header
* Support in total up to 5V/3A, 15W LED Strip
• 1 x CPU Fan Connector (4-pin)
* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
• 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)
* The CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CPU_OPT/W_PUMP can auto detect if 3-pin or 4-pin fan is
in use.
• 1 x Chassis Fan Connector (4-pin)
* The Chassis Fan Connector supports the chassis fan of maxi-
mum 1A (12W) fan power.
• 1 x 24 pin ATX Power Connector (Hi-Density Power Con-
nector)
• 1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
• 1 x Front Panel Audio Connector (15μ Gold Audio Connec-
tor)
• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports
ESD Protection)
• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
(Supports ESD Protection)
• 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
(Supports ESD Protection)
TM
Processors)*
TM
Technology
