3. Layout, Connections & LED's

3.1 Layout

Front:
Reset Button Status LED
RXD LED
Back:
3.2 Connections & LED's
DB 9M:
RJ45 Port:
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
4x Seriell 9 Pin D-SUB Stecker
PoE LED
RJ45 Port
Serial 9 Pin D-SUB Connector
Pin Signal
1 DCD
2 RXD
3 TXD
RJ45 Port
Pin Signal Pin
1 BI_DA+
2 BI_DA-
3 BI_DB+
14
TXD LED
Power/ACT LED
5-24V T-Block 5-24V DC Connector for
for optional included Power Supply
Power Supply
Pin Signal
4 DTR
5 GROUND
6 DSR
Signal Pin
4 BI_DC+ 7
5 BI_DC- 8
6 BI_DB-
EX-6114PoE
Pin Signal
7 RTS
8 CTS
9 (Power)
Signal
BI_DD+
BI_DD-
