Electrical Connection - Electronic SCE18 fast Montageanleitung

Electrical connection

The unit must only be mounted by an electrician.
The national and international regulations for the installation of
electrical equipment must be observed.
Voltage supply for units up to 60 V to EN50178, SELV, PELV.
Disconnect power before connecting the unit.
Wiring diagramm:
1
2
3
Adernfarben bei ifm-Kabeldosen:
1 = BN (braun), 2 = WH (weiß), 3 = BU (blau), 4 = BK (schwarz).
BN
L +
/
BK
4
BU
L
Steckeransicht
3
BU
L +
/
2
BK
4
1
BN
L
(am Gerät)
1
4
2
3
7
