Function
Once the SensorLight has to the wall mount, the system
been connected and attached can be switched on. Three set-
a) Twilight setting
You can set the light to
come "ON" at any light level
from approx. 2 lux to 2000
lux. Control turned fully
clockwise means daytime
operation at approx. 2000
lux. Control turned fully
anticlockwise means twi-
light operation at approx. 2
lux. (Light is set to daytime
operation on leaving the
b) Switch-off delay (time
setting)
The "ON" time can be var-
ied continuously between
approx. 10 sec. and a
maximum of 15 min. Con-
trol turned fully clockwise
means shortest time of
approx. 10 sec., control
turned fully anticlockwise
means longest time, ap-
approx. 10 sec. – max. of 15 min.
prox. 15 min. (Light is set to
Infinitely variable
brightness control
(Watt-o-matic)
The following functions
can be controlled using the
dimmer:
1) Control turned fully clock-
wise means that the Sen-
sorLight is switched
"OFF". The light on-
ly switches to maxi-
0 – 50 %
mum output when move-
ment occurs in the sensor
zone.
2) Turning the control from
the middle setting to ful-
ly anticlockwise infinite-
ly varies SensorLight
brightness from approx.
10 watts to a max. of 30
watts (light "ON" perman-
10
ting controls are provided on
the light's sensor lens.
factory.) The SensorLight
control must be turned fully
clockwise when adjusting
the detection zone and
performing the function test
in daylight.
shortest time on leaving the
factory.) The shortest time
setting is recommended
when adjusting the Sen-
sorLight's detection zone
and performing the func-
tion test.
ently). This means: At
a permanent light "ON"
setting, for example, of
30 watts, the light will
only switch to maximum
output (60 watts) when
movement occurs in the
sensor zone.
3) Dimmer control turned
fully anticlockwise and
twilight setting control
turned fully clockwise:
In this setting, the Sen-
sorLight is permanent-
ly "ON". Using an "ON/
OFF" switch fitted in the
building's electrical wir-
ing system, the Sensor-
Light can be operated as
a normal light.

Operation

If you want the connected influences may affect the
load to come on independ- function of the SensorLight.
ently of a heat source in the In case of strong gusts
detection zone, briefly oper- of wind, snow, rain and
ate the indoor mains power hail, switching errors may
switch. The connected load occur, since the sudden
is subsequently activated temperature deviations can-
for the set time. Weather not be distinguished from

Technical Specifications

Power supply:
Output:
Power consumption:
Detection angle of sensor:
Swivelling range of the sensor:
"ON" time, adjustable:
Twilight setting, adjustable:
Sensor reach (dependent on the sensor
setting, ambient temperature and
direction of approach):
from the front:
from the side:
Type of enclosure, splashproof:
sources of heat. The multi-
lens (detector lens) can be
cleaned with a damp cloth
if it gets dirty (do not use
cleaning agents).
220 – 240 V/50 – 60 Hz
60 W bulb max.
0.7 W
360° all-round detection
(with 120° angle of aperture)
2 x 40° in either direction
10 sec. - 15 min.
2 lux – 2000 lux
12 m max.
6 m max.
IP 44
