PARTS DESCRIPTION

Battery holder and fan unit
► Fig.1
1 Battery holder
(10.8 V - 12 V max)
(optional accessory)
Model DFJ210 / DFJ211 / DFJ310 / DFJ311 / DFJ410 / DFJ411
► Fig.2
1 Loop for name badge
5 Shoulder pad
(DFJ410 / DFJ411 only)
Model DFJ212 / DFJ213 / DFJ214 / DFV210
► Fig.3
1 Battery pocket
INSTALLATION
Installing or removing the battery
cartridge
CAUTION:
Always switch off the device
before installing or removing the battery
cartridge.
CAUTION:
Hold the battery holder and the
battery cartridge firmly when installing or remov-
ing the battery cartridge. Failure to hold the battery
holder and the battery cartridge firmly may cause
them to slip out of your hands and result in damage
to the battery holder and battery cartridge and/or a
personal injury.
► Fig.4: 1. Red indicator 2. Button 3. Battery cartridge
4. Battery holder (optional accessory)
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert the battery cartridge all the way until
it locks in place with a small click. If you can see the red
indicator on the upper side of the button, it is not locked
completely.
To remove the battery cartridge, slide it from the battery
holder while pressing the button on the front of the
cartridge.
CAUTION:
Always install the battery car-
tridge fully until the red indicator cannot be seen.
Otherwise the battery cartridge may accidentally
fall out of the battery holder, causing injury to you or
someone around you.
CAUTION:
Do not forcibly install the battery
cartridge. If the battery cartridge does not slide in
easily, it is not being inserted correctly.
2 Battery holder
(14.4 V /18 V)
(optional accessory)
2 Loop for arm badge
6 Mesh pocket for ice pack
2 Hood
(DFJ212 only)
10 ENGLISH
3 Fan unit
3 Sleeve holder
7 Anti-slip rubber
(DFJ211, DFJ311 and
DFJ411 only)
3 Hook and loop fastener
(DFJ212 only)
Attaching the battery holder
You can hang the battery holder on your waist belt.
To prevent the battery holder from dropping acciden-
tally, attach a strap using the strap hole and secure it.
► Fig.5: 1. Strap hole
For 18V and 14.4V battery holders
The battery holder has an anti-drop function. When
removing the battery holder from the belt, pull up the
battery holder while pressing the unlock button.
► Fig.6: 1. Unlock button
Installing or removing the fan unit
1.
(For DFJ212 / DFJ213 / DFJ214 / DFV210 only)
Open the zip fastener before installing or removing the
fan unit.
► Fig.7
2. Turn the ring counterclockwise while lifting the
hook on it. Remove the ring when the mark on the ring
aligns with the slot on the fan unit.
► Fig.8: 1. Fan unit 2. Ring 3. Hook 4. Slot 5. Mark
3. Pass the head of the fan unit into the hole on the
jacket. Set the ring onto the fan unit and turn it clock-
wise until the mark on the ring aligns with the mark
further from the slot.
► Fig.9: 1. Mark 2. Ring 3. Fan unit
4.
Pass the strip through the loop on the fan unit and
fasten the snap button.
► Fig.10: 1. Strip
5. Attach the other fan unit to the jacket in the same
way.
6. Connect the power cable to the fan units. Support
the cable using the cable holder.
For model DFJ210 / DFJ211 / DFJ310 / DFJ311 /
DFJ410 / DFJ411
► Fig.11: 1. Power cable 2. Cable holder
4 Power cable
4 Battery pocket
8 Hood
(DFJ211, DFJ311 and
DFJ411 only)
4 Light reflector
(DFJ214 only)
