Technical specifications:

Dimensions:
Weight:
Mains lead input:
Supply voltage:
Power consumption:
On/Off switch:
Operational indication:
Tone control:
Volume control:
Output:
Output current:
Loop:
Recommended loop
resistance:
Recommended wire diameter:
Surface loop:
Frequency range:
Inputs:
Output:
Selector switch:
Warranty:
The product fulfils the requirements of the following EC directives:
Low voltage: 2006/95/EC
Electro-magnetic compatibility: EN 61000-6-3:2007, EN 61000-6-1:2007
EMC with respect to CE – marking: 2004/108/EC
All manuals and user guides at all-guides.com
length 22.5 cm; width 12 cm; height 5 cm
827 gram
C8
230 V a.c.
Max. 20 VA
Yes (primary side transformer)
Yes, with LED from input selection.
Single knob, high/low +/- 6 dB
Yes
Current controlled
1 A continuous, 4 A peak
Simple
0.4.... 1 Ohm
2
0.5 mm for lengths up to 20m
2
0.75 mm for lengths up to 30m
2
1 mm for lengths up to 40m
Maximum 50 m
50 Hz - 8k Hz +/- 2 dB
2 x stereo RCA (cinch-cinch)
1 x microphone 3.5mm
Quick fitting connector (loudspeaker output)
Yes, with LED indication
24 months, after purchase date
17
2 2
(1mm wire)
