Audio connections

The Digiloop 50 is fitted with three audio connections;
2 x line inputs for TV ( ) and audio ( ) and 1 x microphone input ( ).
TV
If your TV has a free scart, you need a scart plug. Connect this to one of the audio
leads. Connect the other end of the audio lead to the TV input of the Digiloop 50
(Figure 2, number 8).
If your TV has an audio output (RCA, cinch) you can connect your audio lead directly
to it and establish a link to the TV input of the Digiloop.

Audio

The output of your audio installation is connected via the audio lead to the input of
the digiloop. (Figure 2, number 9)

Microphone

A microphone (not supplied) can be connected to the Digiloop 50 using a 3.5 mm
jack plug. (Figure 2, number 10)

Operation

Selector switch

The selector switch allows you to choose from various connected audio sources. By
pressing in the knob (Figure 1, number 2) you can select a different output. Your
choice is clearly displayed by the illuminated blue LED (Figure 1, number 3).

Volume control

The volume of the Digiloop 50 can be adjusted using the right hand rotary knob
(Figure 1, number 4).
To increase the volume, turn the knob clockwise.
To reduce the volume, turn the knob anti-clockwise.

Tone control

The tone colour of the sound can be changed by using the left-hand rotary knob
(Figure 1, number 1).
To increase the tone, turn the knob clockwise.
To reduce the tone, turn the knob anti-clockwise.
14
