2. Technical data

Model
Mains voltage / frequency
Performance P1 / P2
Protection class
Flow rate through sand filter
Max. delivery height (Q
max
Max. pressure
Suction port / pressure port
Hose connector
Max. fluid temperature (T
max
Min. fluid temperature (T
min
Grain size of quartz sand
Sand filling quantity
Length of power cord
Type of power cord
Weight of pump
Dimension of filter set
Total weight of filter set
Article No.
1)
The values were determined with free, unreduced in- and outlet.
2)
Quartz sand not included

3. Position and function

The pool filter set should be placed on a level concrete slab, very firm ground, or equivalent approximately 2 to 3
m from the pool edge. Ensure that the ground will not subside, preventing any strain from the attached plumbing.
Protect the set from splash water and humidity. It should not be placed in an earth hole.
Make sure, the inlet of the pump is placed at least 30 cm under the water level of the swimming pool.
Please note the pump shall be placed on a well-ventilated and dry location, which is protected against float-
ing and splash water and easy to reach for maintenance. The pump shall not be placed into a too small cham-
ber or compartment in order to avoid overheating.
Make sure that all electric parts of the pump do not get in touch with water. Dangerous!
The pump is not suited to discharge saltwater, feces, inflammable, etching, explosive or other hazard-
ous liquids. Please observe the max. Temperature of the liquids to be discharged stated in the technical
data.
Function of the sand filter set
Incoming water from the piping system is automatically directed by the 4 position valve to the top of the filter bed.
As the water is pumped through the filter sand, dirt and debris are trapped by the filter bed, and filtered out. The
filtered water is returned from the bottom of the filter tank, through the 4 position valve and back through the pip-
ing system.

4. Range of use

This swimming pool filter set is for cleaning of swimming pool water. This device is for the private use and not for
industrial or commercial usage.
14
1)
)
)
)
SPF 180 E
220-240 V~ / 50 Hz
250 Watt / 180 Watt
IPX5
4,500 l/h
7,900 l/h
0.6 bar
45,48 mm (1½") female
32 mm (1¼"), 38 mm (1½")
40° C
5° C
0.5 up to 0.8 mm and 0.7 up to 1.2 mm
10 kg
1.8 m
H07RN-F 3G1.0 mm²
3.9 kg
28,5 x 36,5 x 60,5 cm
7.8 kg
30310
