ENGLISH
HYDRIM M2/M2 G4 Handpiece Adaptor (LCS) Operator Manual
®
2
Luer Lock Fittings
Connecting handpieces to the LCS adaptor
1

Program settings

To ensure maximum wash performance results of the
handpieces and the other instruments, the Technician
needs to increase the wash time to the maximum setting
of 15 minutes for the cycle.
Note: The overall cycle time will increase accordingly by
about 6 minutes.
Please note: As recommended by leading manufacturer/suppliers of handpieces, the hollow parts of instruments should be dried immediately after cleaning and disinfection using
medical compressed air before additional processes or sterilization. This is to be followed by recommended regular maintenance procedures and application of maintenance
agents/oils. Please follow all applicable health & safety regulations for your region.

Using the touchscreen menu

The HYDRIM will
automatically detect
the presence of the
LCS adaptor. Select
the desired program
and follow the prompts.
Upon completion, open
the door and remove
the handpieces from the
adaptor by pushing on the
tab at the side of the port.
1
2
Multiflex
Intramatic
Insert the handpiece coupling into the handpiece.
Example: Regular cycle
1
2
Coupling
MULTIflex - p/n 01-113930
or
INTRAmatic - p/n 01-113931
with adaptor
(not included)
3
Handpiece
(not included)
3
Push the handpiece into one
of the ports.
Please note: As recommended
by leading manufacturer/suppliers
of handpieces, the hollow parts
of instruments should be dried
immediately after cleaning and
disinfection using medical compressed
air before additional processes or
sterilization. This is to be followed by
recommended regular maintenance
procedures and application of
maintenance agents/oils. Please
follow all applicable health & safety
regulations for your region.
Push tab
to release
