4) PRODUCT OVERVIEW

Refer to the figures {A} to {I} on page II:
1 Cartridge guide
2 Plunger discs*
3 Dispense volume indicator
4 Pneumatic drive unit
5 Cartridge ejector button
6 Cartridge holder*
7 Trigger
8 Pressure regulation valve
9 Handle
10 Retract Button
11 Retaining Nut
12 Nose Plug
13 Instruction handbook
14 Compressed air connection
* available as a spare part

Safety instructions stickers

Variants / type designations

The versions of the dispenser are listed in the table
below:
Type Cylinder Ø
2693824 70 mm
2693825 100 mm
EN
Cartridge
Ratios
volume
200 ml
1:1 / 2:1 /
4:1 / 10:1
400 ml
5 of 10

5) FUNCTIONAL DESCRIPTION

Refer to the figures {A} to {I} on page II:
The air pressure in the pneumatic circuit is lowered by
the pressure regulation valve (8). Air Pressure drives a
cylinder piston which moves the mounted plungers (2)
into the cartridge tubes and forces material into the
static mixer.
6) PREPARING THE DISPENSER
FOR USE

Connect to air line

Refer to the figure {A} on page II:
1. Install desired ¼" NPTF or BSPPF quick-release
coupling (not included) using two wrenches to
tighten.
2. Connect dispenser to compressed air line and verify
connection for air leaks. May need to tighten
connection if leaks are discovered.

Mounting the plunger discs

Refer to figure {J} on page III:
1. Select the largest possible plunger discs for the
cartridges you want to use.
2. Fix plunger discs in place with allen head screws.
Check the correct fixture of the plunger discs peri-
odically.
Instruction handbook EQ HD14
Version 1.0 · 27.10.20
