MICROHD HD400
Both inputs of the HD400, INPUT 1 and INPUT 2 are laid out as
(1)
1/4" TRS connectors.
Both outputs of the HD400, OUTPUT 1 and OUTPUT 2 are laid
(2)
out as 1/4" TRS connectors.
SERIAL NUMBER. The serial number of the HD400 is located at the
bottom.
◊ ◊
The HD400 is a passive device. Therefore, no power
supply is needed.
Applications
The following figure shows an example of how to use the MicroHD
HD400.
EUROLIVE B1220 PRO
EUROPOWER EP2000
EURORACK UB2222FX-PRO
Example: HD400 wiring
Output L Output R
EUROLIVE B1220 PRO
EUROPOWER EP2000
MicroHD HD400
