AC Voltage
RANGE
50Hz -- 500Hz
400.0mV*
4.000V, 40.00V, 400.0V
1000V
CMRR :
Input Impedance : 10M, 30pF nominal (1000M for 400.0mV range)
*Selection by RANGE button manually, and is specified from AC 10mV (AC 40mV
for True RMS model BM807s) and up
DC Current
RANGE
400.0A
4000A
40.00mA
400.0mA
4.000A
10.00A*
*10A continuous, 20A for 30 second max with 5 minutes cool down interval
AC Current
RANGE Accuracy
50Hz -- 500Hz
400.0A
4000A
40.00mA
400.0mA
4.000A
10.00A*
*10A continuous, 20A for 30 second max with 5 minutes cool down interval
Diode Tester
Open Circuit Voltage
< 1.6 VDC
Type-K Temperature (BM807s)
RANGE
-20 OC TO 300 OC
-4 OF TO 572 OF
*Type-K thermocouple range & accuracy not included
Elma 805/807
>60dB @ DC to 60Hz, Rs=1k
Accuracy
2.0% + 5d
1.2% + 3d
2.0% + 5d
1.2% + 3d
2.0% + 5d
1.2% + 3d
1)
Burden Voltage
2.0% + 6d
1.5% + 4d
2.0% + 6d
1.7% + 4d
2.0% + 6d
1.8% + 4d
Accuracy 1)
4.0% + 5d
1.5% + 5d
4.0% + 5d
Burden Voltage
0.15mV/A
0.15mV/A
3.3mV/mA
3.3mV/mA
0.03V/A
0.03V/A
0.15mV/A
0.15mV/A
3.3mV/mA
3.3mV/mA
0.03V/A
0.03V/A
Test Current (Typical)
0.25mA
Accuracy*
2% + 3 OC
2% + 6 OF
