ASSEMBLING
Assembly of the oar
Assemble the section of the oar by depressing the spring loaded pin and inserting
the sections of oar until the pins lock into their retaining holes.
Installation of oars
Insert the bolt on the swivel oarlock into the central hole on the oar shaft. Screw
the retaining nut onto the end of the bolt and position the oar into the oar holder.
