Zusatzinformation Additonal Information ACS-8 Netzteilauswahl und Einstellung ACS-8 Mains/Charger Unit Selection and Settings P31903-80-002-00 Änderungen vorbehalten Subject to change without notice 2021-04-15...
Seite 2
Art.-Nr. 013950 Netz-/Ladeteil 12V DC / 26 Ah Art.-Nr. 013960 Netz-/Ladeteil 12V DC / 52 Ah Einbauhinweis • Entfernen Sie, wie in Abbildung 2 markiert, den gekennzeichneten Bolzen auf der ACS-8 Gehäuserückwand / Gehäuseboden. • Montieren Sie das Netzteil wie in Kap. 10 der Installationsanleitung ACS-8 beschrieben.
Seite 3
Mains/charger unit 12V DC / 52 Ah Installation note • Remove the marked bolt on the ACS-8 enclosure rear housing side / enclosure base as marked in Figure 2. • Mount the Mains/Charger unit as described in chapter 10 of the ACS-8 installation instructions.
