UNDER-TABLE MOUNTING

For under-table mounting, there are two M4 screw holes located on the upper edge of both sides of the housing. Use the included M4
flat-headed screws to tightly screw the two rack-mount brackets
er can now be attached in a suitable position below a desktop.
05.06.2019
V1
23 22 21
05.06.2019
V1
23 22 21
(rack-mount bracket included in optionally available rack mounting kit LDIMARK).
A
20 19
20 19
D
D
A
with short sides to each side of the housing as illustrated. The amplifi-
