Dymo RHINO 6000 Kurzanleitung Seite 5

3. Inserting the label cassette
Your printer comes with two RHINO label cassettes.
Visit www.dymo.com for information about purchasing additional
label cassettes.
To insert the label cassette
Lift the label cassette cover to open the
1.
label compartment. See Figure 4.
Make sure the label and ribbon are taut
2.
across the mouth of the cassette and that
the label passes between the guideposts. If
necessary, turn the spool clockwise to
tighten the ribbon.
Insert the cassette and press gently until
3.
the cassette is eased into place.
Make sure the two blue clips lock the
4.
cassette in place. Refer to the label on
the cassette.
Close the label cassette cover.
5.
To remove the label cassette
Lift the label cassette cover to open the label cassette compartment.
1.
Press the Eject button. The label cassette is automatically lifted.
2.
Replace the cassette as described above.
3.
Lift
Figure 4
Eject
Button
3
