Warming surface with infrared lamp description
This product is specifically designed to keep the temperature of food placed over the heating surfaces
constant. It is characterised by a highly simplified construction in order to reduce the possibility of
malfunctions to a minimum and facilitate maintenance.
The heating surface is fully constructed with stainless steel AISI 304 18/10 with galvanized steel sheet metal
bottom cover.
The resistance is attached under the heating surface.
The heating surface is distinguished by infrared lamps placed above the surface to increase its already high
heating capacity.
4 rubber feet can be applied to the bottom of the heating surface for support and insulation.
Controls to turn on the machine and set temperature are found on the long side of the surface.

Technical specifications

Descriptions
Power supply
Nominal power
Net weight
Packaged weight
Installation
Protection level
Electrical shock protection
Conformity with directives
and norms

Overall dimensions

mm A B
PCI4717
420 700
PCI4718
PCI4718D
mm A B
400 650
PCI4717
330 550
PCI4718
555
PCI4718D 330
Unit of measure
V Hz Ph
W
Kg
Kg
C
940
C
600
680
680
INFORMATION
PCI 4717 PCI 4718
230V 50Hz
750
9
12
Counter
IPX4
Class I
2014/30/CE – 2014/35/CE – 1935-2004-CE
5
GENERAL
PCI 4718D
1Ph
500 750
10 8
14 11
1
