CONNECTION
4:
FOUR
CABLE
METHOD
Connect
GE300
Lite
to
FX
Loop
of
guitar
amp.
In
this
method,
users
could
enjoy
the
stomp

boxes
in
GE300
Lite
with
their
own
amps.

Here
is
the
setting
procedure:
1.
Turn
on
FX
Loop
block
in
GE300
Lite
.
Turn
off
AMP
and
CAB
bloacks.
2.
Set
FX
Loop
to Serial
＂
3.
Place
stomp
boxes
like
wah,
compressor,
pre-EQ,
octave
effects
before SEND ;






Place
modulation,
delay,
reverb
effects
after
RETURN.
FOUR
CABLE
METHOD :
Turn
on
FX
LOOP
block.
Turn
off
AMP
and
CAB
blocks.
Set
FX
Loop
to

Serial .
Place
stompboxes
such
as
wah,
compression,
pre-EQ,
octave,
etc.,
before
SEND.

＂ ＂
Modulation,
Delay,
reverb
effects
are
recommended
to
be
placed
after
RETURN.
GUITAR
EXP1
INPUT
GUITAR
EXP2
Connecting
to
Guitar
Amplifier
or
traditional
FX
LOOP:
We
recommend
turning

off
AMP
and
CAB
blocks.
＂
FX
LOOP
RETURN
AMP
INPUT
FX
LOOP
SEND
SEND









L(MONO)
OUTPUT
RETURN
R
XLR
OUT










L(MONO)
R
