Congratulations on your purchase!
With the CUBE Race you have acquired a wireless electronic bike computer with state of the art electronics,
the highest level of precision and it is weatherproof. As special features the Race has an optional cadence
measurement and an optional heart rate measurement (for this you need separately available accessories ).
The Two in One-System: this allows you to use this cycle computer for two different bicycles and view the
combined total values.
Please read this operating manual carefully.
Lieferumfang:
- CUBE Race
- battery type CR 2032
- battery cap
- handlebar bracket
- transmitter
- cable ties for mounting
- spoke magnet
A
A1
1. Mounting
The handlebar bracket can be mounted on the handlebar and
also on the stem.
Picture A: Mounting is possible on handlebar (Position A-1) or
stem (Position A-2).
Picture B: For using it on the stem, change bracket mounting
orientation from Position A to Position B.
Remove the protective tape.
A2
Place the handle bar and fasten it with the cable ties.
Picture C: Mount the transmitter with cable ties on the fork
(max. distance to the handlebar bracket max. 60 cm; best
mounting on the right side, handlebar bracket and transmitter
should be on the same side).
Picture D: Fix the magnet on a spoke so that it will face the
mark on the transmitter. Adjust the magnet position and fine
tune the sensor if necessary (distance between transmitter and
magnet max. 3 mm).
Picture E: Rotate the Race to 45 degree left and install it into
B
the bracket. Then rotate it 45 degrees right to lock it. To unlock,
rotate 45 degrees to the left.
1.1 Mounting of optional cadenceset
(separately available)
Mount the handlebar as described above on the handlebar or on
the stem.
Place the sensor on the cable on the left chain-brace in height
of the crank with help of cable-ties so that it is still loose enough
to be lined up. Mount the cadence-magnet (with help of a cable
tie) on the inside of the crank. The distance between magnet and
sensor should be max. 3 mm.
The magnets must point directly to the mark on the sensor. Now
90ϒ
switch on the cadence measuring in the setting mode of the
Race (see chap. 2.1). Turn crank a few times to check if the
mounting is correct. Now tighten the cable-ties.
1.2 Putting on the heart rate transmission belt
Warning: whoever carries out sport should have a general
medical check up on his/her general state of health - especially
beginners, persons older than 35 years of age and anyone who
has suffered from illnesses or injuries in the past. It is recom-
mended that a doctor be consulted in any case in the presence
of risk factors, such as smoking, high blood pressure, high
cholesterol values, diabetes, lack of exercise and excess weight.
Pacemaker wearers should consult their doctor before
using any heart rate measurement device!
The transmitter belt is hung in the elastic chest belt and fastened
around the upper body. The transmitter (plastic part with the
CUBE-logo) should lie over the middle of the upper stomach,
immediately below the breastbone, so that the logo on the
transmitter is legible (viewed from the front) (see illustration). The
electrodes in the belt, to the right and left of the transmitter, must
be in contact with the skin.
C
Pull the belt tight so that it cannot slip and constant contact with
the body is guaranteed during movement.
If the Race fails to display any heart rate, it probably means
that there is no contact between the skin and the electrodes.
Moistening the electrodes and the underlying skin often helps.
Best results are obtained if electrode gel is used (available from
pharmacies).
Measurement of the heart rate is only possible if the transmitter
belt is fitted correctly and the Race is within the transmitter's
reception range (max. 60 cm).
D
2. Preparation
Inserting the battery
Insert battery type CR2032 with plus-pole facing up. Close
battery cap with a coin, being sure not to over tighten. After
inserting the battery the display will show normal mode.
(If nothing or incomprehensible signs appear in the display, press
the AC-button on the rear of the computer with help of a ballpoint
pen or a similar object. Attention: this will delete all values and
setting).
2.1 Settings
Enter setting mode by pressing middle button for 3
E
seconds. Display shows 'SET BIKE1'.
To quit setting mode press again middle button for 3 seconds in
any setting.
(To change the display to german language, press left button
45ϒ
short, display shows ‚LANGUAGE'. Press middle button to choose
this function and then switch between 'English' and 'Deutsch'
with right button. To store press left button and then get back to
setting mode with short pressing of right button).
KLICK!
Though Race can show german and english words, this manual
shows both possible displays.
The different setting modes can be shown by pressing
right or left button, by pressing middle button the shown
setting mode is chosen.
Possible setting modes:
SET BIKE1 / SET RAD1
F
SET CLOCK / SET UHR
SET HR / SET HF
SET MISC
EXIT / ENDE
LANGUAGE / SPRACHE
Each setting mode can have different setting possibilities.
The following is valid for these settings: the blinking
value can be changed with the right button, the value is
stored by shortly pressing the left button and the next
value blinks or the next value appears on the display.
G
Tire size
Circumference
40-559
26 x 1,5
2026 mm
44-559
26 x 1,6
2051 mm
47-559
26 x 1,75
2070 mm
50-559
26 x 1,9
2026 mm
54-559
26 x 2,00
2089 mm
57-559
26 x 2,125
2114 mm
37-590
26 x 1 3/8
2133 mm
32-620
27 x 1 1/4
2199 mm
40-622
28 x 1,5
2224 mm
47-622
28 x 1,75
2268 mm
40-635
28 x 1 1/2
2265 mm
37-622
28 x 1 3/8
2205 mm
20-622
700 x 20C
2114 mm
23-622
700 x 23C
2133 mm
25-622
700 x 25C
2146 mm
28-622
700 x 28C
2149 mm
32-622
700 x 32C
2174 mm
USA
OPERATING MANUAL
For a better reading in the following chapters the setting modes
are fat printed and the settings fatanditalic.
SET BIKE1 / SET RAD1
Adjustment of bike-specific values, e.g. total distance, circum-
ference, unit and more for bike 1.
Choose with middle button.
To do these settings for bike 2, press right and left button short
simultaneously in normal mode. Race switches to bike 2, then
enter again setting mode (display then shows SET BIKE2/SET
RAD2).
DAYDST/TAGES-DST
Adjustment of the daily distance
Default: 000.00 km
Range: 000,00 to 999,99 km or m
Set with right and left button, store with left button.
Here the daily distance can be adjusted, e.g. the point of starting
a tour, when using a printed tour-guide.
(This setting doesn't change the total distance. There only really
ridden kilometres are counted).
TOTDST/GES.DST
Adjustment of the total distance
Default: 0000 km
Range: 0 to 99999 km or m.
Set with right and left button, store with left button.
Here the total distance can be adjusted.
Wheel/Radumf.
Adjustment of circumference
Default: 2080 mm
Range: 1000-3999 mm
Set with right and left button, store with left button.
Here the circumference can be adjusted.
The circumference of the wheel can be taken from the
chart (Pict. G) or be measured by yourself.
Measuring the circumference of the
wheel (for a more precise setting):
Put a marking at the front-tire and on the
ground (e.g. with chalk). Ride straight
ahead exactly one turn of a tire (for a very
exact measurement, check the pressure of the tire before getting
on your bike) and mark this position on the ground. Now measure
the exact circumference of the wheel between the two markings
at the ground (in mm) – see pict. F.
Unitkmbzw.Unitmi
Adjustment of the measuring unit (kilometres or miles)
Default: km
Set with right button, store with left button
Here you can choose whether the display should show kilometres
(km/h) or miles (m/h).
CADOFF/TRITTAUS
Switch cadence on/off (ON/AN – OFF/AUS)
Default: OFF/AUS
Set with right button, store with left button
Here you can switch on/off the cadence measuring. To use this
function you need the optional cadence-set (available at your
local dealer).
SET CLOCK / SET UHR
Adjustment of clock, date and clocktime-format.
Choose with middle button
Time/Uhrzeit
Adjustment of clock
Range: 00:00 to 23:59 or 12:00 to 11:59 A/P
Set with right and left button, store with left button
Here you can set the current clocktime. First you set the hours,
then the minutes.
Year/Jahr
Adjustment of the year
Default: 2007
Range: 2007 to 2099
Set with right button, store with left button
Here you can set the current year.
Month/Monat
Adjustment of the month
Default: 01
Range: 01 to 12
Set with right button, store with left button
Here you can set the current month.
Day/Tag
Adjustment of the day
Default: 01
Range: 01 to 31
Set with right button, store with left button
Here you can set the current day.
Clock/Zeit
Adjustment of the clock format
Default: 24
Set with right button, store with left button
Here you can select between 24- or 12-hour format (AM/PM).
SET HR / SET HF
Adjustments for the optional heart rate measurement. To use this
function you need the optional heart rate-set (available at your
local dealer).
HROFF/ON/HFEIN/AUS
Switch heart rate on/off (ON/AN – OFF/AUS)
Default: OFF/AUS
Set with right button, store with left button
Here you can switch on/off the heart rate measuring.
Fitness/Fitness
Adjustment of the fitness level.
Default: 3
Set with right button, store with left button.
Range 1-4, corresponding to the following levels:
1 – poor fitness
2 – average fitness
3 – good fitness
4 – high fitness
Here you set your personal fitness level, necessary for the
CUBEInZone-calculation. Sex/Geschlecht
Set with right button, store with left button.
Change between
Range: 0 to 999,99 km or mi
m = male and f = female.
The sex is needed for the CUBEInZone-calculation and the
TOT-Gesamtdistanz(pict. 6)
calorie consumption.
Sub-function of function daily distance
Indicates the total distance ridden up to now in kilometres or
Weight/Gewicht
miles (since last reset or battery change).
Range: 20 to 220 kg
Range: 0 to 99999 km or mi
Set with right and left button, store with left button
The weight is needed for the CUBEInZone-calculation and the
∑TOT-sumoftotaldistanceofbike1andbike2(pict. 7)
calorie consumption.
Sub-function of function daily distance
Indicates the sum of the total distance ridden up to now in
Birthdate/Gebjahr
kilometres or miles (since last reset or battery change) of bike 1
Adjust with right and left button, store with left button
and bike 2.
Default: 1960
Range: 0 to 199999 km or mi
Range: 1920 to 2006
The year of birth is necessary for the CUBEInZone-calculation.
Ø average speed (pict. 8)
Indicates the current average speed in km/h or mi/h.
InZone
Range: 0 to 199,9 km/h or m/h (the decimal place is high-
Here you can start the CUBEInZone-calculation by short pressing
ranking)
of right and left button simultaneously (see also chap. 4 for
CUBEInZone).
MAX-maximumspeed(pict. 9)
In order to ignore the calculation, just press short left button.
Sub-function of function average speed
Indicates the highest speed ridden up to now in km/h or mi/h.
In order to obtain an exact calculation of ones personal
Range: 0 to 199,9 km/h or m/h (the decimal place is high-
CUBEInZone it is necessary to insert the personal data relative to
ranking)
fitness-level, sex, weight and birthdate.
In order to calculate the CUBEInZone position the chest belt
Time (pict. 10)
correctly, take up a rest position (remain seated and relaxed) and
Indicates the current time.
start the CUBEInZone calculation by short pressing of right and
Range: 00:00:00 to 23:59:59 or 12:00:00 to 11:59:59 AM/PM
left button simultaneously.
The Race will then start to time 5 minutes. During this time, stay
Date(pict. 11)
seated, relaxed and calm, as the Race will measure the minimum
Sub-function of function time
heart rate reached during this period (heart rate at rest) and will
Indicates the current date (dd.mm.yy).
store this value for the subsequent calculation.
TM daily ride time (pict. 12)
After the 5 minutes the lower value of the calculated personal
CUBEInZone appears in the display.
Indicates the current daily ride time.
Range: 0 to 9:59:59 h
LowerHR/untereHF
A lower heart rate limit can be set here or (after CUBEInZone-
TOT-totalride-time(pict. 13)
calculation) the calculated value is shown.
Sub-function of function daily ride time
When the current heart rate is lower than this value, the Race
Indicates the total ride time (since last reset or battery change).
shows an arrow (t) as an optical alarm.
Range: 0 to 999:59 h
Range: 0 to 220 bpm
Adjust with right and left button, store with left button
∑TOT-sumoftotalridetimeofbike1andbike2
(pict. 14)
UpperHR/obereHF
Sub-function of function daily ride time
An upper heart rate limit can be set here or (after CUBEInZone-
Indicates the sum of the total ride time (since last reset or battery
calculation) the calculated value is shown.
change) of bike 1 and bike 2.
When the current heart rate is higher than this value, the Race
Range: 0 to 999:59 h
shows an arrow (s) as an optical alarm.
Range: 0 to 240 bpm
The following function only appears, if switched on in the
Adjust with right and left button, store with left button
setting mode (for the measuring of the cadence you need the
separately available cadence set).
MaxHR/MaxHF
Shows the maximum heart rate, calculated with CUBEInZone.
CAD cadence (pict. 15)
Range: 0 to 240 bpm
Indicates the current cadence (rpm = rounds per minute)
Adjust with right and left button, store with left button
Range: 0 to 250 rpm
SET MISC
Ø-averagecadence(pict. 16)
Here you can switch on the powerdown-mode or make a reset
Sub-function of function cadence
(delete all values).
Indicates the average cadence.
Choose with middle button
Range: 0 to 250 rpm
Powerdown/STROMSPAR
MAX-maximumcadence(pict. 17)
Switch on the powerdown-mode (e.g. before changing of the
Sub-function of function cadence
battery, to save the values).
Indicates the maximum reached cadence.
To switch it on, press right and left button short simultaneously,
Range: 0 to 250 rpm
display fades out and Race is in powerdown-mode. By short
pressing of any button, Race starts again and shows normal
The following functions (heart rate and calorie consumption) only
mode.
appear, if heart rate is switched on in the setting mode (for the
measuring of heart rate you need the separately available heart
Reset/Löschen
rate-set).
Here you can delete all values (including the total values). For this
press right and left button short simultaneously, display shows
HR heart rate (pict.18)
'reset' and then normal mode.
Indicates the current heart rate (bpm = beats per minute)
Range: 0 to 250 bpm
If you only want to delete the day values, press right and left
On the right side of the lower display an arrow shows, whether
button for three seconds in normal mode.
the current heart rate is below (t), within (ts) or above (s)
the set heart rate limits.
3. Functions
Ø average heart rate (Bild 19)
The Race has an automatic start/stop when on the handlebar
Sub-function of heart rate function
bracket.
Indicates the average heart rate (since last reset).
That means, 4 sec. after the first wheel turn the display shows
Range: 0 to 240 bpm
normal mode and the current speed.
1 minute after the last wheel turn (and without a button is
MAX maximum heart rate (Bild 20)
pressed) the display changes to an "energy save" mode. During
Sub-function of heart rate function
this mode, only the time is displayed.
Indicates the maximum heart rate reached (since last reset).
If the wheel turns or a button is pushed, the computer will
Range: 0 to 240 bpm
resume normal functions.
Training time below the lower limit set for heart rate
The optional heart rate measuring works also without speed
(pict. 21)
signal: when Race is in normal mode (by pressing any button or
Sub-function of the heart rate measurement function.
auto-start), the heart rate receiver is automatically switched on.
Displays the training time during which heart rate dropped below
And as long as a heart rate is shown in the display, there is no
the lower limit set.
automatically switching to sleep mode.
(since last reset).
Range: 0 to 9:59:59 h
To change from bike 1 to bike 2 (and back) press right and left
button short simultaneously (in the left part of the display the 1
Training time within the limits set for heart rate (pict. 22)
changes to 2 and back).
Sub-function of the heart rate function.
Indicates the training time during which heart rate was within the
To reset all day values, press right and left button for
limits set (since last reset).
three seconds.
Range: 0 to 9:59:59 h
The Race has a three-lined display. In the middle part always
Training time above the upper limit set for heart rate
the current speed is shown, with a small 1 or 2 left beside, that
(pict. 23)
shows whether the current values are valid for bike 1 or bike 2.
Sub-function of heart rate function.
Indicates the training time during which heart rate exceeded the
To advance the functions of the upper display, press right
upper limit set (since last reset).
button, to advance the functions of the lower display press
Range: 0 to 9:59:59 h
left button.
Always short pressing of the middle button shows the sub
kCal Calorie consumption (pict. 24)
functions of the function in the lower display. Functions in
Indicates the current calorie consumption (since last reset).
the upper display:
Range: 0 to 99999 kCal
TM – Daily ridetime (pict. 2)
Heartrate – if switched on (pict. 3)
TOT total calorie consumption (pict. 25)
DST – Daily distance (pict. 4)
Sub-function of calorie consumption function
Time (pict. 1)
Indicates the total calorie consumption (since last reset or
(Explanation of these functions see ‚functions in the lower
battery change)
display')
Range: 0 to 99999 kCal
4. CUBEInZone
Function in the middle display:
SPD – current speed
CUBEInZone
your training routine.
Inidcates the current speed in km/h or m/h .
It is possible to calculate the optimum training threshold with the
Range: 0 to 199,9 km/h or m/h
An arrow on the left side of the display indicates, whether the
CUBEInZone
your pulse rate when at rest.
current speed is faster (arrow up) or slower (arrow down) than
CUBEInZone
the current average speed.
applied to any sport, from jogging and cross-country running to
road and indoor cycling.
Improve your fitness? – Lose weight? – Train whilst always taking
your health into consideration? Everyone will find the correct aim
to follow in their training. But how do you train to achieve those
Functions in the lower display:
aims in the most efficient possible manner? How do you find the
DST daily distance (pict. 5)
right intensity of effort during the training? CUBEInZone
optimum training ZONE for effort, resistance and weight loss.
Indicates the distance ridden up to now in kilometres or miles..
Guarantee certificate:
Sender:
Name
irst name
Street, No.
Code/Location
Telephone (during the day)
Fax
E-Mail
Reason for return:
After expiry of the guarantee: Repairs should be carried out up to a value of Euro ____________
What does CUBEInZone
It calculates the optimum training zone for effort, resistance and
weight loss.
The values vary from person to person and they offer a valid
training support – always staying between 70 % and 85 % of the
maximum heart rate.
(+/- 5% of tolerance, taking into consideration the actual heart
rate when at rest and the level of training).
The question of burning fat is seen in the "correct" light with
CUBEInZone
– on the basis of the personal data collected.
®
5 . Battery change
Race: Open battery cap with a coin (unscrew to the left). Insert
battery type CR2032 (please use battery with smooth minus-
pole) with plus-pole facing up. Close battery cap, being sure not
to over tighten. After inserting the battery the display will show
normal mode.
If nothing or incomprehensible signs appear in the display, press
the AC-button on the rear of the computer with help of a ballpoint
pen or a similar object. Attention: this will delete all values and
setting.
(Battery change in the optional chest belt works in the same
way.)
Transmitter: Open battery cap at the top of the transmitter with
a coin (unscrew to the left), remove old battery and insert new
12 V battery, type 23A (with pluspole facing up). Close battery
cap, being sure not to over tighten.
Please do not throw away battery in your normal garbage.
6. Trouble shooting
Faulty or no display
- check to see if battery is installed properly or replace battery
(Attention: removing battery will clear all settings and values in
the Race)
- press AC-button on the rear of the computer
Speed not displayed
- check to see if wheel-sensor is mounted properly
- check the position of the spoke magnet (max. 3 mm distance
to wheel-sensor)
- make sure Race is mounted in bracket correctly
- check wheel circumference
Speed to high or to low
- check wheel circumference
- check to see if you are using miles or kilometers
No heart rate displayed or values displayed are incorrect
or unstable
- proof whether heart rate is switched on in setting mode
- Check transmitter belt (battery)
- Skin too dry or cold
- Distance between Race and transmitter belt is too great (max.
60 cm)
Cadence is not displayed or value incorrect or unstable
- Check whether switched on in setting mode
- Check sensor and magnet for correct installation
7. Guarantee
We offer a guarantee for 24 months from the date of purchase
on the Race. The guarantee is limited to material and proces s ing
faults. The batteries are excluded from the guarantee.
The guarantee is valid only if the computer, with accessories, has
been handled and maintained carefully and according to opera-
ting instructions.
To return the Race under conditions/terms of the guarantee,
please refer to your dealer, your local distributor or send the
computer with the proof of purchase (date) and all accessories
and with sufficient postage, to:
C CUBE Service
Pending System GmbH & Co KG
Ludwig-Hüttner-Str. 5-7
D-95679 Waldershof
Tel.: +49 9231 97007 80
Fax: +49 9231 97007 60
info@CUBE.eu
www.CUBE.eu
Please read through the instruction manual carefully before
sending us your computer and check the battery. An exchange-
device or the repaired device will sent back to you free of charge
if justifiable guarantee-claims have come into question. Please
contact our local distributor.
Repair:
If your Race is sent in for repair (or battery change) or if a
guarantee claim is not valid, repairs up to EUR 19.- will be
carried out automatically.
In case of higher repair costs you will be notified. The repaired
device will be sent back COD.
Philosophie und Anwendung
®
is a solution for the very best personalisation of
®
function on the basis of your personal data and
®
is the ideal solution for personalised cardio training
®
is the
®
do?
®
Werbung
