TURNTABLE / PLATTENSPIELER INSTRUCTION MANUAL BEDIENUNGSANLEITUNG ASCONA...
Seite 2
Dank für Ihr Vertrauen in unser Produkt, den ble Ascona Neo With the purchase of your turntable you Plattenspieler Ascona Neo Mit dem Kauf dieses Plattenspie- acquired a precision instrument for the play-back of records.
Packing Verpackung Parts Teile Chassis Ascona Neo with arm base Chassis Ascona Neo mit Armbasis Subplatter Subteller Baseplate Basisplatte Platter Plattenteller Digital Motor Control DMC-20 Digitale Motorsteuerung DMC-20 Tool set Werkzeugsatz Power cord Netzanschlusskabel Patch cable RJ45 red Patchkabel RJ45 rot...
Seite 4
Setup Aufbau Preparation Vorbereitung To avoid transport damages the Ascona Neo Um Transportschäden zu vermeiden wird der comes in a carefully designed packing (2 boxes) Plattenspieler sorgfältig verpackt (2 Kartons) and is partially preassembled. und teilweise vormontiert geliefert. We recommend having a plane area of about Für den Aufbau benötigen Sie eine ebene Fläche...
Mounting the subplatter Subteller montieren Before mounting the subplatter, remove the mo- Nehmen Sie vor Beginn der weiteren Arbeiten tor cover, using an Allen key size 2 for the 6 hex zuerst die Motorabdeckung ab. Dazu lösen Sie screws of the lid. Put the cover aside. die Sechskantschrauben mit einem Inbusschlüs- sel Gr.
Mounting the belts Antriebsriemen montieren Place each of the 3 provided belts around 2 pul- Legen Sie die 3 mitgelieferten Riemen einzeln leys and the subplatter as shown in the pictures jeweils um 2 Pulleys und den Subteller begin- below, starting with the lowest groove (Groove nend mit der untersten Nut (Nut 4).
Mounting the platter Teller montieren Place the platter carefully on top of the subplat- Setzen Sie den Teller vorsichtig auf den Subtel- ter as shown in the picture above. Make sure ler auf, wie im obigen Bild dargestellt. Achten that both cylinders and contacting planes (sub- Sie darauf, dass beide Zylinder und Kontaktflä- platter and platter) are free of any dirt.
Seite 8
3 M4 x 20 Schrauben auf der Oberseite des key size 3. Armboards (Inbus Grösse 3). Your Ascona Neo can carry up to 3 tonearms. Ihr Ascona Neo kann bis zu 3 Tonarme tragen. To mount a new arm base you may need to...
Connecting the Ascona Neo Den Ascona anschliessen Connect the Ascona Neo in 3 steps: Schliessen Sie den Ascona in 3 Schritten an: - Patch cable RJ45 red - Patchkabel RJ45 rot - Patch cable RJ45 blue - Patchkabel RJ45 blau...
Zum Ändern der Drehzahl drücken Sie die Ge- (marked with 33/45). schwindigkeitstaste (beschriftet mit 33/45). As long as the Ascona Neo speeds up or down, Solange der Teller seine Solldrehzahl noch nicht the target speed LED is blinking. When the blink- erreicht hat, blinkt die entsprechende LED.
Seite 12
Ascona Neo Technical data Technische Daten Dimensions: Abmessungen: 483mm** x 460mm x 200mm 483mm** x 460mm x 20mm 19“ x 18,1“ x 7,9“ ** depending on position of arm base ** abhängig von der Position der Armbasis Weight: Gewicht: Approx. 60kg / 132lbs Ca.
