4.4 Size of the electrical cables

Always use cables of a suitable cross-section. The minimum cross-sections are listed
in the table below:
Cross-section in
mm²
2.5
4
6
10

4.5 Internal lighting

In order to replace the LED light bulb, slide the lighting unit's glass down using the
appropriate lever. Replace the light bulb and to return the lighting unit to its original
state (Fig. 4-5).
Only use original Indel Webasto Marine Srl spare parts.
Max 12 V cable length
AWG section
m/ft
13
11
9
7
Max 24V cable length
m/ft
2.5/8
4/13
6/19
10/33
5/16
8/26
12/39
20/66
