O P E R A T I N G I N S T R U C T I O N S
Mini-PC box "Minix Neo X5"
Item no. 39 43 80
Intended Use
The product enables any monitor or television set that has a free HDMI input to be upgraded to a
Smart TV.
Using the Android operating system, you have access to numerous apps through the Google Play
Store. Wireless access to the Internet is possible through the integrated WLAN function; however, a
10/100MBit network connection is also available.
The power is supplied by the enclosed mains adaptor.
The safety instructions must be observed at all times!
Any use other than the one described above could lead to damage to this product and present a
hazard of short circuits, fi re, electric shock, etc. No part of the product may be modifi ed or converted!
This product complies with the applicable national and European requirements. All names of compa-
nies and products are the trademarks of the respective owners. All rights reserved.
HDMI is a registered trademark of HDMI Licensing L.L.C.
Package Contents
• Mini PC box
• Wall plug transformer
• USB cable
• USB-OTG cable
• HDMI cable
• Quick guide
• Manufacturer's operation instructions (in English)
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe
these safety instructions! We do not assume any liability for any resulting
damage!
We shall not accept liability for damage to property or personal injury caused
by incorrect handling or non-compliance with the safety instructions! In such
cases, the warranty will be null and void.
• The unauthorised conversion and/or modifi cation of the product is not permitted for
safety and approval reasons (CE). Never dismantle the product.
• The product is not a toy. Devices operated using mains voltage must be kept out of the
reach of children. Therefore, be especially careful when children are around.
Use the product where it is out of the reach of children.
• The product is intended for use only in dry, indoor locations. No part of the product
should become damp or wet; never handle it if your hands are wet!
Wall plug transformers have the potential to cause a fatal electric shock!
• The design of the wall plug transformer complies with Protection Class II. Use only a
standard mains socket as the power source for the wall plug transformer.
The mains socket into which the wall plug transformer is plugged must be easily acces-
sible.
• Do not pull the wall plug transformer from the mains socket by pulling on the cable. Hold
it on the sides of the casing and pull it out of the mains socket.
• If the wall plug transformer is damaged, do not touch it; there is life hazard from electric
shock!
First, switch off the mains voltage to the socket to which the wall plug transformer is
connected (switch off at the corresponding circuit breaker or remove the safety fuse or
switch off at the corresponding RCD protective switch, so that the socket is fully discon-
nected).
You can then unplug the wall plug transformer from the mains socket. Dispose of the
faulty wall plug transformer in an environmentally friendly way, do not use it any more.
Replace it with a wall plug transformer of the same design.
• Do not leave the packaging material carelessly lying around, since it could become a
dangerous plaything for children.
• Handle the product with care; it can be damaged by impacts, blows, or accidental falls,
even from a low height.
Connection and Getting Started
• If desired, insert an SD/SDHC memory card into the corresponding slot of the Mini PC box. Videos,
music or images on the card can be displayed or played back later.
• Connect the HDMI output of the Mini PC box with the provided HDMI cable to a free HDMI input of
your monitor or television.
Furthermore, an optical TOSLINK output, a headphone and microphone connection (each a
3.5 mm jack socket) and a 10/100MBit network connection are available.
• To operate the Mini PC box, you need a USB keyboard and USB mouse. You can use, for example,
a wireless keyboard/mouse for this purpose so that a cable-free operation is made possible.
www.conrad.com
Version 03/13
• Connect the low-voltage round socket of the Mini PC box to the corresponding round plug of the
provided wall plug transformer; then plug the latter into a mains socket.
• Switch the Mini PC box on by pressing and holding the Power button for approx. 2-3 seconds.
The Mini PC box starts now; this can (as with switching on an Android mobile phone) take several
seconds. Finally, the Start screen appears.
The operation is similar to an Android mobile phone; pay attention to the enclosed (English) opera-
ting instructions from the manufacturer.
To switch it off, press and hold the Power button until a message appears on the screen prompting
you to confi rm.
If you keep the Power button depressed for more than 8 seconds, the Mini PC box is directly
switched off; however, doing so can in some circumstances (e.g. when a data transfer is in
progress) lead to a loss of data.
• First select the desired language in the Setup menu; then enter the corresponding data for access
to your network or WLAN. Then you can enter the access data for the Google Play Store account or
create a new access; after that, you are able to download and install apps, just like with an Android
mobile phone.
Maintenance and Care
Prior to cleaning the device, pull the wall plug transformer out of the mains socket.
Use a clean, dry, soft cloth for cleaning. Do not use aggressive cleaning agents, as these can cause
discolouration. Do not press too strongly on the surface when cleaning, to prevent scratch marks.
Dust can easily be removed using a clean, long-haired brush and a vacuum cleaner.
Disposal
Declaration of Conformity (DOC)
We, Conrad Electronic, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declare that this product
conforms to the fundamental requirements and the other relevant regulations of the directive 1999/5/EC.
Technical Data
a) Mini PC box
CPU .............................................. Cortex A9, Dual-Core (2x 1.6 GHz)
Memory ......................................... 1 GB DDR3, 16GB Flash (a portion of this is required for the
Graphics chip ................................ Mali400, Quad-Core
WLAN ........................................... 802.11b/g/n
LAN ............................................... 10/100MBit
Bluetooth ...................................... 4.0 (HS)
USB Ports ..................................... 3x USB2.0
Memory card slot .......................... yes, SD-type, max. 32GByte
Dimensions ................................... 128 x 128 x 22 mm (L x W x H)
b) Wall plug transformer
Operating voltage ......................... 100 - 240 V/AC, 50/60 Hz
Output ........................................... 5 V/DC, 3 A
The Mini PC box itself requires a current of approx. 1 A; using the provided power cable
with an output current of 3 A, there is still enough power available, for example, to operate
an external 6.35 cm/2.5" USB hard drive.
If multiple USB devices with a high power consumption need to be operated, connect a
USB hub with its own power supply to the Mini PC box.
Please dispose of the device when it is no longer of use, according to the current statutory
requirements.
The Declaration of Conformity for this product can be found at www.conrad.com.
operating system, so the entire memory is not available for free
access!)
These operating instructions are a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1,
D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfi lming,
or the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in
technology and equipment reserved.
© Copyright 2013 by Conrad Electronic SE.
