Scope Of Delivery; Commissioning; Starting The Device - T.I.P. Sweeper 18000 3D Original-Gebrauchsanweisung

Model
Max. pool size
Filter capacity
Operating temperature
Runtime options
Robot degree of protection / protection class
Switch box degree of protection / protection class
Net weight
Item no.

4. Scope of delivery

Included in the product scope of supply are:
A pool robot with connection cable, switch box (transformer) with connection cable, filter baskets, operating man-
ual.
If possible, retain the packaging until your guarantee has expired. Dispose of packing materials in an environmen-
tally friendly manner.

5. Commissioning

5.1 Placement of the switch box:
The switch box must be mounted on a wall, fence, post, shed or on a level and solid surface, at a safe distance of
at least 3 metres from the edge of the pool (Fig. 1). Use the eyelets provided on the back for this purpose (Fig. 2).
Make sure that the cleaner can reach all corners and ends of the pool.
Place the switch box away from direct sunlight and rain.
It is advisable to connect the device to a current circuit with an earth leakage circuit breaker.
Fig. 1
5.2 Connecting the pool robot to the switch box:
Unscrew the protective cap of the cable connection on the switch box and connect the cable connection of the
pool robot (Fig. 3.1). Then tighten this clockwise (Fig. 3.2).
Please make sure that you unscrew the cable connection and put the protective cap back on the connection when
dismantling or wintering. The device must then be stored in a dry and frost-free place.
Fig. 3.1

5.3 Starting the device:

Carefully and slowly lower the cleaner into the pool using the handle. Make sure that the cleaner is always insert-
ed with its underside facing the pool wall and that it is also removed this way subsequently.
10
Sweeper 18000 3D
70 m³
100 µm
10 – 35 °C
3
IPX8 / III (safety extra-low voltage)
IPX4 / I
12.5 kg
30455
Fig. 2
Fig. 3.2
3
