5) MACHINE OPERATION WARNING LIGHT (GREEN):
It indicates that the machine is working.
6) OVERCURRENT CIRCUIT BREAKER:
It intervenes when there is overcurrent, interrupting the machine supply. Its intervention is indicated by the expulsion of the
manual reset. In case of intervention of the circuit breaker, wait a few minutes and reset it by pressing its central pin.
7) LASER MARKER (Optional on 70xxx0)
It projects the cutting line on the table. It is enabled when the machine is connected to the mains.
CUTTING ON THE TABLE
21
BEFORE STARTING THE CUTTING OPERATIONS, THE OPERATOR MUST MAKE SURE THAT AT LEAST 150 cm
ARE LEFT FREE AROUND THE MACHINE. IN ORDER TO WORK IN SAFETY CONDITIONS, DO NOT LET OTHER
PEOPLE REMAIN NEAR THE MACHINE DURING THE CUTTING OPERATIONS. BEFORE PERFORMING THE
CUTTING OPERATIONS, MAKE SURE THAT THE MATERIAL IS PROPERLY LEANED AGAINST THE TILE STOPPER.
CUTTING FOR THICKNESS OF UP TO 110 mm
22
With the locking lever, lower the motor head until placing the cutting blade some millimetres below the working table level.
23
• Arrange the piece to be cut on the working table at the desired measurement;
23
• Start the machine and wait until cutting blade cooling water comes out, adjusting the necessary amount by means of the
water on-off valve located on the blade guard, and cut;
CUTTING FOR THICKNESS OF UP TO 180 mm
24
By adjusting the position of the cutting head using the locking lever, it is possible to cut materials of a height of up to 180 mm
in two passages. By making use of the graded index located on the side of the motor head, lower the head until reaching the
desired measurement.
• By means of the cutting square, arrange the piece to be cut on the working table at the desired measurement.
24
• Start the machine and carry out the first cut.
25
• Turn over the piece 180°, and repeat the cut.
CUTTING A SURFACE AT 45°
Before positioning the motor head, make sure that:
• the machine is off; • the cutting tool is not moving;
45° CUTTING FOR THICKNESS OF UP TO:
45 mm
65 mm
Referring to the graded scale located on the machine upright, move the motor head to the 45° position and tighten the knobs.
26
• With the locking lever, lower the cutting head until placing the blade some millimetres below the table level;
27
28 • Arrange the piece to be cut on the working table at the desired measurement;
28 • Start the machine and wait until cutting blade cooling water comes out, adjusting the necessary amount by means of the water
on-off valve located on the blade guard, and cut.
LASER MARKER
STANDARD FOR ART. 90551, 90851, 91001, 91201,
91501 and 92001.CLASS IIIA LASER INSTRUMENT
By means of the laser marker accessory, the cutting operations can be accelerated.
As a matter of fact, the special laser system is able to indicate the tool cutting line on the working table.
THE LASER MARKER STARTS WORKING ONCE THE MACHINE IS CONNECTED TO THE POWER SUPPLY.
DIRECT EXPOSURE TO SUNLIGHT MAY REDUCE THE LASER MARKER EFFECTIVENESS.
IT IS THEREFORE ADVISABLE TO USE THE MACHINE INDOORS.
29
CUTTING WITH LASER MARKER
• connect the machine to the power supply;
• position the piece to be cut making sure that the line indicated by the laser marker matches the reference on the material to be cut;
• perform the cutting operation as indicated in the paragraph: "CUTTING ON THE TABLE".
DO NOT MODIFY THE MARKER POSITION BY TURNING THE BEAM TOWARDS THE OPERATOR'S EYES. DO NOT
GAZE AT THE BEAM WITH THE NAKED EYE OR LOOK DIRECTLY WITH OPTICAL INSTRUMENTS.
MARKER ADJUSTMENT
In case the marker is not aligned with the cutting line, its correct alignment can be adjusted.
In order to correctly position the marker, proceed as follows:
30
• loosen the three bulb locking screws so that it can be moved;
GB
Ø 250 mm blade
Ø 300 mm blade
