Telephone Subscriber Card G8-TEL4
Please contact your sales partner to receive the necessary
programs and manuals.
The digital telephone card G8-TEL4 allows connection of up to four analogue
telephones to the centrals GE 800 and GE 300 (with GEI 300).
Connection via installation boards
For the connection of the analogue telephones to the G8-TEL4 two different instal-
lation boards are available: G8A-K and G8A-I.
These installation boards as well as the transformer for the external power supply
(e.g. PA9) are not included in the extent of supply.
Installation board G8A-K for one G8-TEL4
Installation board G8A-K for one G8-TEL4 with pluggable screw-terminals; this in-
stallation board occupies one plug-in unit at the rear of the central.
Attention:
The connection diagram below must be followed!
G8A-K no.1
A,B:Telephone
C,D: Loudspeaker
PWR: 24 VAC, 80 VA
PWR
230 V
24 V
PWR
G8A-K no.2
Installation board G8A-I for one G8-TEL4
Installation board G8A-I for a single G8-TEL4 with a 37-way D-Submin plug; occu-
pies one plug-in unit at the rear of the central.
For connection to the distribution board prefabricated cables are available:
X-ASK32/5: 32-way cable, 5 m (16.4 ft)
X-ASK32/10: 32-way cable, 10 m (32.8 ft)
A1
B1
C1
D1
A2
B2
C2
D2
A3
B3
C3
D3
A4
B4
C4
D4
NC
NC
NC
NC
PWR1
PWR1
PWR2
PWR2
PWR1
PWR1
PWR2
PWR2
NC
NC
NC
NC
NC
NC
NC
NC
NC
G8A-I
5 m or 10 m cable
(16.4 ft or 32.8 ft)
Note: For technical data as well as required hard- and software, see appropriate
datasheet.
For current software and documentation please visit:
www.software-manuals.com
Attention
Observe the precautions for handling of electrostatic sensitive devices!
The card may be only installed by authorised engineers.
Manufacturer's reference
This equipment fulfils the requirements of the EU standard 89/336 EEC
in the current version (EN 55022, EN 55024).
Therefore this equipment is CE-labelled.
Please keep this description in safe custody!
Type: D-BZ-G8-TEL4, Version: 1.0/0409
1st subscriber
whiteblue:
A1
blue:
B1
whiteblue
:
C1
yellow:
D1
2nd subscriber
whiteblue
:
A2
green:
B2
whiteblue
:
C2
A,B:Telephone
brown:
D2
C,D: Loudspeaker
3rd subscriber
whiteblue
:
A3
PWR1, PWR2:
black:
B3
24 VAC, 80 VA
whiteyellow: C3
blue
:
D3
4th subscriber
whiteyellow: A4
Colour code
yellow:
B4
whiteyellow: C4
green:
D4
POWER
whitegreen: PWR1
blue:
PWR1
whitegreen PWR2
e.g.:
yellow:
PWR2
whitegreen: PWR1
230 V
green:
PWR1
whitegreen PWR2
24 V
brown:
PWR2
