PRODUCT OVERVIEW
1
2
3
4
ASSEMBLY INSTRUCTIONS
•
The heater is packaged with the feet unattached. You must attach them before
operating the heater.
WARNING: Do not operate without feet attached. Only operate the heater in an upright
position (feet on the bottom, controls on the top), any other position could create a
hazardous situation.
1.
Place the radiator body upside-down on a scratch-free location, make sure it is
stable and will not fall.
2.
Remove the wing nuts from the U-bolt provided (see Fig 1), insert the U-shaped
bolt around the flange between first pair of fins (near the front cover) (see Fig 2).
3.
Insert the threaded ends of the U bolt through the holes on the castor mounting
plate (see Fig 3).
4.
Screw the wing nuts back on to the U bolt and tighten (see Fig 4).
5.
Repeat with the rear castor inserting the U-bolt between rearmost pair of fins
Note: do not over-tighten, as this may cause the damage of radiator flange.
INSTRUCTIONS FOR USE
•
Before using the heater, make sure that it is on a flat and stable surface. Damage
may occur if it is placed on an incline or uneven surface.
•
Set all the controls to OFF position and insert the plug into a mains socket
•
Rotate the thermostat knob clockwise to MAX position and switch the heater on.
•
Switch I is for low heat, switch II for medium heat and turn both switches on for
high heat. When the heating element is on the power switch will illuminate.
1. Carry handle
2. Power switches
3. Thermostat control
4. Cord storage
5. Radiator fins
6. Castors
5
6
GB
