6 | TECHNICAL SPECIFICATIONS

System type 2-way vented box
LF 8" custom woofer - 1.5 V.C.
HF 3" - 0.5" V.C.
Amplifier D Class
Output power 20W RMS (d.c. power) – 50W RMS (a.c. power)
Frequency response 65Hz - 18kHz
MAX SPL 113dB
Protections Short circuit, overvoltage, overload protection
Controls CH 1 Level, CH 2 Level, Reverb, Master, Contour
Indicators Power, 5 battery status LEDs
Mic inputs 2x (1 alternative to instrument input CH 2)
Mic input connections XLR/6,35mm. (1/4") jack combo
Line input 2x (1 alternative to CH 2 microphone input)
Line input connections CH2 - 2 x 6.35mm (1/4 ") jacks, CH3 - 3.5mm jack.
Power supply 100-240V~ 50-60Hz
Fuse T1,6A L 250V~
Power consumption 50 W
Battery VRLA type rechargeable 12V / 5Ah
Battery protection ON/OFF switch
Cabinet material High density polypropylene
Dimensions 381 x 525 x 210 (mm)
(W x H x D) 15" x 20,7" x 8,3"
Weight 9,8kg (21.6 lbs)
Other features 2x transport wheels, telescopic handle, upper carrying handle,
retractable support for 35 degrees system inclination

MEDIA PLAYER

Available I/O Bluetooth, USB stick, AUX in
Bluetooth version 5.0
®
Compatible formats MP3, WMA, WAV
Mode (AUX/Bluetooth/USB), Play/Pause, previous song, next song,
Media Player controls
level increase, level decrease
Media Player display Dual 7-segment display
