Usb Mode - ANT iROLLER8 Bedienungsanleitung

4.1 | BLUETOOTH MENU
®
The following operations concern Bluetooth
to section 4.2. The MP3 player is equipped with Bluetooth
it possible to play audio files from another external device (such as a Smartphone) on
your iROLLER 8 as long as the distance between the two devices is within 10 meters.
To synchronize and connect the MP3 player with a device equipped with Bluetooth
technology, use the following procedure:
1. Briefly press the MODE button until when the bt logo flashes.
2. Activate the Bluetooth of your device to search for the receiver built into the
®
Media Player.
3. In devices list detected by your smartphone or tablet, select "iROLLER 8" to synchronize
your device with the Media Player.
4. After synchronization, the bt logo remains lit on the display and the unit emits an
acoustic signal of procedure completion. Once finished you can start playing the
songs.
WARNING: Syncronized Bluetooth device music playback can be stopped and resumed
®
by pressing the PLAY/PAUSE button

4.2 | USB MODE

USB stick has priority over the other inputs. By inserting the USB stick the Bluetooth
and LINE/AUX inputs are automatically disabled. The listening level can be adjusted
using the and buttons.
iROLLER 8
10 User manual |
mode menu. For USB stick operations, refer
®
technology, which makes
®
.
5 | TROUBLESHOOTING
PROBLEM LEDS
No sound or
very low Battery level leds off.
®
sound level
Battery level leds on
but master lowered
Battery level leds lit, master
raised but low input channel level.
Battery level leds on, master up
and media player in playback.
Battery status red light on.
®
No system
power up in
battery mode
Distortion Peak led lit.
Voice not clear
SOLUTION
Make sure the device is
properly connected to the
power outlet and/or the
battery is not discharged.
Raise MASTER level.
Check the connections
between the sources and the
mixer.
Raise inputs LEVEL.
Check CH 3 selector.
Check MEDIA PLAYER source
(LINE/AUX, USB or bt).
Adjust VOL via .
Charge the battery.
Verify that the BATTERY
OPERATION selector is set
to ON
Lower level of CH1, 2, 3 inputs
and/or MASTER level.
Lower "REVERB" level
iROLLER 8
11
| User manual
