EN
Commissioning
Pairing room thermostats and
heating zones
One or more heating zones must be paired
to each Geberit room thermostat. This
applies to both wired and wireless room
thermostats.
1
Press and hold the <OK> button on
the Geberit main control unit for
2 seconds.
2
Press the <▷> button.
3
Press the <OK> button.
✓ The [PAIRING] and [ZONE 1]
LEDs flash.
4
On the Geberit room thermostat you
wish to select for heating zone 1,
press and hold the <+> and <->
buttons simultaneously for
2 seconds.
✓ [PAIr] is displayed on the room
thermostat.
✓ Following successful pairing, the
number of the paired heating
zone is displayed for 3 seconds
(e.g. [ZonE 1]).
✓ The [PAIRING] and [ZONE 2]
LEDs flash on the Geberit main
control unit.
5
On the Geberit room thermostat you
wish to select for heating zone 2,
press and hold the <+> and <->
buttons simultaneously for
2 seconds.
✓ [PAIr] is displayed on the room
thermostat.
✓ Following successful pairing, the
number of the paired heating
zone is displayed for 3 seconds.
✓ The [PAIRING] and [ZONE 3]
LEDs flash on the Geberit main
control unit.
12
6
Repeat the above steps until all
heating zones have been paired.
7
Press and hold the <OK> button on
the Geberit main control unit for
2 seconds.
✓ The LEDs of the paired zones
and the [PAIRING] LED light up.
8
Press and hold the <OK> button on
the Geberit main control unit for
2 seconds.
✓ The room thermostats and
heating zones are paired and the
main control unit returns to its
initial state.
Setting the daytime
temperature
1
Press the <+> button.
✓ The daytime temperature is
displayed.
2
Use the <+> or <-> button to set the
daytime temperature.
3
Press and hold the <Info> button until
the basic display appears.
Result
✓ The daytime temperature is now saved.
