Snap the upper housing section into
the base plate.
9007202977626379-1 © 03-2018
968.339.00.0 (00)

Explanation of symbols

1 First indicator on display
2 Second indicator on display
3 Third indicator on display
4 Fourth indicator on display
5 <+> button
6 <Info> button
7 <-> button
Symbol Description
Room temperature
measurement
Outdoor temperature
measurement
Daytime temperature
Nighttime temperature
Frost protection temperature
Room heating
Room cooling
Data and settings menu
