3 – Attaching the mounting brackets to the TV
Check to see how the mounting holes are arranged on the back side of your television set. Select the proper
bolts for your TV. Attach both mounting brackets to the TV with two screws (A1–A4), spacer (A5) and washer (A6).
Tighten the bolts firmly, but not too much.
Selecting a suitable washer
hole (A6) according to the screw
size
Diameter M8 (A4)
M5 and M6 diameter
(A2 + A3)
Diameter M4 (A1)
Warning: If the holes on the back of your TV are too shallow and none of the included screws fit into them, use
the appropriate screws of your choice.
