or more off -set electrifi ed wires of an electric animal fence. The suppor ng devices for the
electrifi ed wires shall be constructed so as to ensure that these wires are posi oned at a
minimum distance of 150 mm from the ver cal plane of the non-electrifi ed wires. The barbed
wire and razor wire shall be earthed at regular intervals.
• Follow the installa on instruc ons regarding earthing.
• A distance of at least 10 m shall be maintained between the energizer earth electrode and any
other earthing system connected parts such as the power supply system protec ve earth or
the telecommunica on system earth.
• Connec ng leads that are run inside buildings shall be eff ec vely insulated from the earthed
structural parts of the building. This may be achieved by using insulated high voltage cable.
• Connec ng leads that are run underground shall be run in conduit of insula ng material or
else insulated high voltage lead-out cable shall be used. Care must be taken to avoid damage
to the connec ng leads due to the eff ects of animal hooves or tractor wheels sinking into the
ground.
• Connec ng leads shall not be installed in the same conduit as the mains supply wiring,
communica on cables or data cables.
• Connec ng leads and electric animal fence wires shall not cross above overhead power or
communica on lines.
• Crossings with overhead power lines shall be avoided wherever possible. If such a crossing
cannot be avoided it shall be made underneath the power line and as nearly as possible at
right angles to it.
• If connec ng leads and electric animal fence wires are installed near an overhead power line,
the clearances shall not be less than those shown in the table below.
Minimum clearances from power lines for electric animal fences
Power line Voltage V
Less than or equal to 1 000
Greater than 1 000 and less than or equal to 33 000
Greater than 33 000
• If connec ng leads and electric animal fence wires are installed near an overhead power line,
their height above the ground shall not exceed 3 m.
This height applies either side of the orthogonal projec on of the outermost conductors of
the power line on the ground surface, for a distance of:
- 2 m for power lines opera ng at a nominal voltage not exceeding 1 000 V;
- 15 m for power lines opera ng at a nominal voltage exceeding 1 000 V.
• Electric animal fences intended for deterring birds, household pet containment or training
4
Gallagher 3E5321 S12 Lithium Solar Fence Energizer User Manual
Clearance m
3
4
8
