KWC Boffi MINIMAL Montage- Und Serviceanleitung

by
RIDM03 (H. 260) + RRDM07
RIDM10 (H. 355) + RRDM07
95
135
165/260
40
S= 32 mm.
3/8"
S= 19 mm.
MINIMAL
Istruzioni di montaggio e di assistenza
I
CANNA SINGOLA CON ATTACCO PER LAVABO
Installation and service instructions
GB
SPOUT WITH CONNECTION FOR WASH-BASIN
Instructions de montage et d'entretien
F
LEVIER AVEC CONNECTION POUR LAVABO
Montage- und Serviceanleitung
D
LOCH HAHN MIT BEFESTIGUNG FÜR WASCHBECKEN
30
45
F1/2"
Ø 55
1/2"
S= 24 mm.
85
500
ISTRUZIONI DI MONTAGGIO
RIDM04 (H. 110) + RRDM07
95
15
40
S= 32 mm.
3/8"
S= 19 mm.
-1-
N° MB0213/02
Data: 30.09.2005
Cod: RIDM03
RIDM04
RIDM10
RRDM07
30
135
45
F1/2"
Ø 55
85
500
1/2"
S= 24 mm.
