Acccessories
The logic probe is supplied complete with the following accessories
which may be attached to the probe tip to aid connection:-
1. Spring hook adaptor
2. I.C. tip adaptor
3. Tip insulator
Instruction for use
The C-MOS logic probe has input threshold levels set to 0.3Vpp (logic
0) and 0.7vpp (logic 1) and hence is suitable for checking all C-MOS
logic systems operating from 5V-15V supplies.
Green and red LED's are used to indicate logic 'O' and logic '1'
respectively. The logic state of the relevant I.C. pin can then be
determined by applying the probe tip and observing the response of the
two LED's. The built in pulse stretcher permits the detection and
indication of pulses down to 100ns. Both the tip and power supply
connections are protected against over and reverse voltages.
Note: Power must be derived from the supply rails of the logic system
under test via the red (positive) and black (earth) crocodile clips.
LED display for various inputs
RS Stock No.
('O' = green LED, 'I' = red LED)
424-096
Specification
Normal working voltage: __________________________5V-15V d.c.
Note: Probe leads must be connected to supply of the logic under test.
Typical input current: ______________±20/15/10µA @ 15/10/5V d.c.
Typical input capacitance: ______________________________20pF
Logic 'O' threshold: __________________________0.30Vpp ±5%Vpp
Logic 'I' threshold: __________________________0.70Vpp ±5%Vpp
Max. supply current: __________________________________45mA
Max. detectable square wave: ______________________10MHz typ
typical detectable single shot pulse width: ________________100ns
Max. voltage to supply leads:____________________________±30V
Max. probe voltage: __________________________________±100V
RS Components shall not be liable for any liability or loss of any nature (howsoever
caused and whether or not due to RS Components' negligence) which may result
from the use of any information provided in RS technical literature.
01/2001
C-MOS logic probe
C-MOS-logiktaster
Sonda lógica de C-MOS
Sonde logique C-MOS
Sonda logica C-MOS
C-MOS logiksonde
C-MOS logische sonde
C-MOS logikprob
Display Input
Both off Open circuit or between 'O' and 'I' threshold
'O' on Below logic 'O' threshold
'I' on Above logic 'I' threshold
Both flash Square wave or repetitive wide pulses (>100ms)
Frequency <100Hz LED's follow input waveform
Both on Square wave or repetitive wide pulses
Frequency >100Hz
'O' Flashes Repetitive, narrow, positive going pulses at repetition
rate <100Hz. Single negative going pulses down to
100ns cause 'O' LED to flash on for approximately
100ms
'I' flashes Repetitive, narrow, negative going pulses at
repetition rate <100Hz. Single positive going pulses
down to 100ns cause 'I' LED to flash on for
approximately 100ms
