Conrad P7898 Bedienungsanleitung Seite 2

G
O P E R A T I N G I N S T R U C T I O N S
Insect Repellent P7898
Item no. 1168854
Intended Use
The insect repellent P7898 is used to expel and keep mosquitoes away.
Any use other than that described above could lead to damage to this product and involves the risk of short
circuits, fire, electric shock, etc. The safety instructions have to be followed without fail!
Explanation of the Symbols
A triangle containing a lightning symbol indicates a health hazard, e.g. electric shock.
This symbol, an exclamation mark in a triangle, indicates particular dangers associated with
handling, function or operation.
The "hand" symbol indicates special information and advice on operating the device.
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe these safety
instructions! We do not assume any liability for any resulting damage!
We do not assume any liability for material and personal damage caused by improper use
or non-compliance with the safety instructions. The warranty will be void in such cases.
• The product must not be modified or converted, as not only will the CE approval become void but also the
warranty.
• Power is supplied by 2x 1.5V Mignon batteries of the type AA or the low-voltage socket (3V DC / 250 mA).
• The device may not be exposed to extreme temperatures, strong vibrations, moisture or heavy mechanical
stress.
• The device is approved for use only in dry indoor locations.
• A damaged device must no longer be used and must be disposed of.
• The product is not a toy and should be kept out of the reach of children.
• Do not leave packaging materials unattended. Plastic film, etc. can be a dangerous plaything for children;
there is a risk of suffocation. It may become a dangerous plaything for children.
• If you are in doubt about how to use the device correctly, concerning its safety, or if you have any questions
not covered by these operating instructions, please contact our technical support or other specialist.
Battery Notes
• Batteries should be kept out of the reach of children.
• Do not leave batteries lying around in the open; there is a risk of them being swallowed by children or
domestic animals. If they are swallowed, consult a doctor immediately.
• Make sure that the polarity is correct when inserting the batteries (pay attention to plus/+ and minus/-).
• Leaking or damaged batteries can lead to caustic burning of the skin. Therefore, use suitable protective
gloves.
• Batteries must not be short-circuited, opened or thrown into fire. There is a risk of explosion!
• Do not recharge normal, non-rechargeable batteries; there is a risk of explosion!
• Never mix batteries of different charge states or different brands.
• If the device is not to be used for a long time (e.g. storage), remove the batteries. Old batteries may leak
and cause damage to the product, which will lead to the loss of the warranty/guarantee.
For the environmentally friendly disposal of batteries and rechargeable batteries, please read the chapter
"Disposal".
Functional Description
The insect repellent P7898 generates a permanent 6 kHz sound.
Mosquitoes and similar insects find this sound unpleasant. This repels such animals or keeps them away
from the range of action of the device.
The insect repellent can be easily carried along anywhere, owing to its battery-powered operation and its
compact and light design. The preferred places of use are bedrooms, living rooms, caravans, etc.
Inserting the Batteries
• Remove the cover of the battery compartment from below.
• Insert the batteries (2x 1.5V Mignon batteries; type AA) in the battery compart-
ment, while paying attention to the correct polarity.
• Close the battery compartment.
Only use batteries of the prescribed type. Use alkaline batteries to achieve as long a period of
operation as possible.
Cold temperatures have a negative influence on the service life of the batteries (reduced operat-
ing time).
Operating with power supply unit
www.conrad.com
Version 04/14
Low-voltage socket polarity: + inside / - outside
Setup and Start-up
The device should be set up to be free-standing. However, the device can be mounted on the wall using the
two openings on the device's rear panel.
Place the device in the direct vicinity of the area to be protected. The device can also be placed close to
windows and doors, so as to prevent mosquitoes from entering the rooms. The device should be set up as a
standalone unit, if possible. Do not place the device behind curtains, furniture items or similar solid objects.
This considerably affects the device's range of action.
Switch the device on or off using the sliding switch on the top of the device. The LED on the top of the device
is lit up during operation.
Maintenance
The product does not require any maintenance. You should never take it apart. The outside of the product
should be cleaned only with a clean, soft, dry cloth. Never use aggressive cleaning agents or chemical solu-
tions since these might damage the surface of the casing or impair the operation
Disposal
a) Product
b) Single-use and rechargeable batteries
As the end user, you are required by law (Battery Regulation) to return used batteries and rechargeable
batteries. Do not dispose of used batteries in the household waste!
You can return your used batteries/rechargeable batteries free of charge at the official collection points of
your community, in our stores, or at places where batteries or rechargeable batteries are sold!
You thereby fulfil your statutory obligations and contribute to the protection of the environment.
Technical Data
Operating voltage for battery-powered operation ............3.0 V/DC (2 x 1.5V Mignon batteries; type AA)
Operating voltage for low-voltage socket ........................3.0 V/DC / 250 mA (+ inside / - outside)
Range of action ...............................................................approx. 20 m²
Frequency ........................................................................6 kHz
Dimensions ......................................................................74 x 76 x 35 mm
Weight .............................................................................60 g (without batteries)
When the product is connected to the mains supply, there must not be any rechargeable or
non-rechargeable batteries in the battery compartment. Remove them before connecting
the device to the power supply unit.
A power supply unit is not part of the delivery. Should the device be operated using a
power supply unit, pay attention to the correct polarity of the low-voltage socket. Please
use only a power supply unit with an output voltage of 3 VDC / 250 mA. Please observe
the safety instructions for the power supply unit during operation.
When drilling, be careful not to damage any power supply lines, gas or water pipes! Risk
of fatal injury!
Never barricade other animals in a room in which the product is operated.
Electronic devices are recyclable waste materials and must not be disposed of in the household
waste!
Please dispose of the product, when it is no longer of use, according to the current statutory
requirements.
Remove any inserted battery and dispose of it separately from the product.
Batteries/rechargeable batteries contain harmful materials and are labelled with the symbol
shown to indicate that disposal in the household waste is forbidden. The symbols of the relevant
heavy metals are: Cd=cadmium, Hg=mercury, Pb=lead (marking can be seen on the battery/
rechargeable battery, e.g., underneath the refuse bin symbol shown on the left).
These operating instructions are a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1,
D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming,
or the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in
technology and equipment reserved.
© Copyright 2014 by Conrad Electronic SE.
