Vivotek FD9392-EHTV-O Schnellinstallationsanleitung Seite 2

4
7
10
5
approx.
15cm
Ø 5 ~ 6.3mm
8
# Name
1 AC 24V
2 AC 24V
3 DC 12V IN-
4 DC 12V IN+
5 DI- (GND)
6 GND
7 DI+_0
8 GND
9 DO-_0
10 DO+ (5V)
11 MIC-IN_N (GND)
12 MIC-IN_P
13 AUDIO-OUT_N (GND)
14 AUDIO-OUT_P
14
- OR -
1
3/4"
≤3/4"
Ø< 35mm
6
9
64 GB
10
1
I
11
