| CONNECTING OTHER SOURCES

CONNECTING SOURCES
The high-quality connectors available on the
rear panel of the DS-10 allow other digital
devices to be connected, making it the core
of a modern audio system.
1
Ethernet
1
Network
USB-A
2
FAT32/NTFS USB flash
memories up to 32Gb
capacity max.
3 AES/EBU
CD Players
Professional digital source
8
2 3
RCA - Coaxial
4
Televisions
DVD Players
CD Players
USB-B
5
Computer
6 TOS-Link
Televisions
DVD Players
CD Players
15
On the DS-10 PLUS, the 3.5mm LINE IN
input can be used to connect analogue
sources, such as the PH-10 phono stage.
7
4 5
7
8
6
Line In
3.5 mini jack preamp mode
(DS-10 PLUS only)
GN Link
12V trigger to link to other
Gold Note models in
Master-Slave mode, with
the master unit turning
ON/OFF the slave units.
