NOTE Sometimes, when removing a keycap you might find that the cap's white
mount insert separates from the cap and remains inside the panel. If this happens
continue to remove the surrounding keycaps to make room, then use your fingers
to remove the keycap mount insert from the panel.
When all the original keycaps have been removed from your advanced panel, you can now fit
the keycap upgrade kit.

Installing the New Keycaps on your Panel

When installing the new keycaps, it's best to work with one panel module at a time with its
matching replacement keycap shelf. As you install each keycap, refer to the 'keycap module
layouts' section later in this manual to assign each keycap to its designated mount.
To install a keycap
1
Align the mount insert of the keycap with the
keycap mount inside the panel. The side tabs
on the keycap insert will fit into the grooves
on the keycap mount.
When you have finished replacing the keycaps on all three sections of your advanced panel,
reconnect the power and launch DaVinci Resolve 17. You can then configure DaVinci Resolve
for the updated panel.
To configure the panel:
1 Go to preferences > control panel
2 From the 'Color Grading Panel' menu, choose 'DaVinci Resolve Advanced Panel 2'
3 Click 'save'

Replacing the Soft Key and Soft Knob Caps

The DaVinci Advanced Panel Keycaps Upgrade also comes with replacement soft key and soft
knob caps. These are direct replacements for the original caps so fitting them is optional.
They're useful if your original soft caps are getting worn.
2
Gently push the keycap into the mount.
The keycap should go into place easily
and engage with a click.
DaVinci Advanced Panel Keycaps Upgrade
