No. 061200
DE - Gebrauchsanleitung
GB - Instruction
DE - Konformitätserklärung
Hiermit erklärt JAMARA e.K., dass das Modell‚ "CCX Pro 2,4 GHz, No. 061200" sich in Übereinstim-
mung mit den grundlegenden Anforderungen und den anderen relevanten Vorschriften der Richtlini-
en 2014/53/EU, 2011/65/EU befi ndet.
Weitere Informationen fi nden Sie auch unter: www.jamara-shop.com/Konformitaet
DE - Entsorgungshinweise
Bitte sorgen Sie für fachgerechte, den gesetzliche Vorschriften entsprechende Entsor-
gung der Elektrobauteile. Bitte werfen Sie diese nur in die dafür vorgesehenen Sammel-
boxen bei den Kommunen.
DE - Dieses ferngesteuerte Modell ist kein Spielzeug!
Geeignet für Personen ab 14 Jahren.
Achtung:
Kinder unter 36 Monaten unbedingt fernhalten. ERSTICKUNGSGEFAHR!
Enthält verschluckbare Kleinteile.
DE - Empfohlenes Zubehör
DE - Empfohlenes Zubehör
8 x AA Batterie, Art.-Nr. 14 0095 (VE 4 Stück)
DE - Highlights
Diese Anlage setzt neue Maßstäbe im RC-Car Bereich. Die bewährte Funktechnik auf 2,4GHz Ba-
sis unserer CCX haben wir übernommen. Ein riesiges Display und eine einfache Programmierung
runden diesen Sender ab.
Ausstattung:
• 3 Kanäle vollprogrammierbar
• 2,4 GHz System
• Dual Rate
• Servorevers
• Justierung Servomitte und Servoendausschläge
• 1024er Aufl ösung
• 100 mW Frequenzhopper
• 10 benennbare Modellspeicher
• Einstellbare Expo-Kurve
• 3-Stufi ge ABS-Funktion einstellbar
• Programmierung über Jog/Dial Rad
• Displaybeleuchtung
• Spannungsanzeige mit akustischer Unterspannungswarnung
• Kompatibel zu bestehenden CCX-Empfänger
• Ladebuchse
• 3,5 mm Klinkenbuchse für Simulatoranschluß
• Gewicht 395g (ohne Batterien)
• Maße 154 x 127 x 270mm
• Programmierbare Fail-Safe am Empfänger
• Displaygröße: 100 x 35 mm
Technische Daten:
Frequenzband
2,4 GHz
Modulationsart
AFHDS
Betriebsspannung
4,8 - 7,4 V DC
Servoaufl ösung
10 Bit (1024 Schritte)
Abmessungen
33 x 22 x 12 mm
Gewicht
5 g
CCX Pro 2,4 GHz
Fernsteuerung | Transmitter
DE - Lieferumfang
• Fernsteuerung
• Empfänger
• Anleitung
DE - Allgemeine Hinweise
JAMARA e.K. übernimmt keine Haftung für
Schäden, die an dem Produkt selbst oder
durch dieses entstehen, sofern diese auf
falsche Bedienung oder Handhabungs-
fehler zurückzuführen sind. Der Kunde
allein trägt die volle Verantwortung für die
richtige Bedienung und Handhabung; dies
umfasst insbesondere die Montage, den
Ladevorgang, die Verwendung bis hin zur
Wahl des Einsatzbereiches. Bitte beach-
ten Sie hierzu die Bedienungs- und Ge-
brauchsanleitung, diese enthält wichtige
Informationen und Warnhinweise.
GB - Certifi cate of Conformity
JAMARA e.K. hereby declares that "CCX Pro 2,4 GHz, No. 061200" follow the regulations and re-
quirements as well as any ther relivant directives of the EEC directive 2014/53/EU and 2011/65/EU.
Further information can also be found at: www.jamara-shop.com/Conformity
GB - Disposal instructions
All parts of this model should be disposed of correctly, in particular electronic components may be
subject to local restrictions. Your dealer will advise you.
GB - This model is not a toy!
Not suitable for people under 14 year.
Warning:
Keep away necessarily children under 36 months. RISK OF SUFFOCATION!
Contains small parts which can be swallowed.
GB - Box contents:
• Transmitter
• Receiver
• Instruction
GB - Recommended Accessories
8 x AA Batteries, Ord. No. 14 0095 (4 pieces)
GB - Features:
This transmitter sets new standards in the RC-Car area. The established 2.4 GHz technology from
our CCX car radio was adopted into the CCX Pro. A huge display and easy programming complete
this transmitter.
Features:
• 3ch fully programmable
• 2,4GHz System
• Dual Rate
• Servo reverse
• Adjustment of servo centre and travel
• 1024 display resolution
• 100mW Frequency hopper
• 10 model memory
• Adjustable Expo
• 3 stage ABS setting
• Programming by Jog/Dial wheel
• Display backlight
• Voltage indicator with audible low voltage warning
• Compatible with CCX receivers
• Charging socket
• 3,5mm jack and simulator connection
• Weight 395g (w/o batteries)
• Dimensions 154 x 127 x 270mm
• Programmable Fail Safe on receiver
• Display: 100 x 35 mm
Technical data:
Frequency
2,4 GHz
Modulation
AFHDS
Operating voltage
4,8 - 7,4 V DC
Servo resolution
10 Bit (1024 steps)
Dimensions
33 x 22 x 12 mm
Weight
5 g
GB - General information
JAMARA e.K. is not liable for any damage
caused to the product itself or by it, if this
is due to improper operation or handling
errors. The customer alone bears the full
responsibility for the proper use and hand-
ling, including in particular, assembling,
charging and using the model, and selec-
ting the area in which to use it. Please re-
fer to the operating and user instructions,
which contain important information and
warnings.
15/16
