28 U-CONTROL UCA222 User Manual
Recording with a preamp such as the
V-AMP 3:
Preamps such as the V-AMP 3 provide a great way to record a
wide selection of high-quality guitar sounds without the hassle
of placing a mic in front of a conventional amp. They also allow
you to record late at night without tempting your roommates
or neighbors to strangle you with your own guitar cable.
• •
Plug a guitar into the instrument input of the V-AMP 3
using a standard ¼" instrument cable.
• •
Connect the stereo ¼" outputs on the V-AMP 3 to the
stereo RCA inputs on the UCA222. This will likely require
adaptors. You may also use the stereo RCA to ¼" TRS cable
that is included in the V-AMP 3/UCA222 package bundle
to connect from the V-AMP 3 headphone output to the
UCA222 RCA inputs.
• • Plug the USB cable into a free USB port on your computer.
The POWER LED will light up.
• •
Adjust the output signal level on the V-AMP 3.
• •
Set the recording program to record input from the UCA222.
• •
Press record and wail!

7. Audio Connections

Although there are various ways to integrate the UCA222 into
your studio or live set-up, the audio connections to be made
will basically be the same in all cases:
7.1 Wiring
Please use standard RCA cables to connect the UCA222
to other equipment:
tip
sleeve
shield
You can also use a ¼" adapter cable:
sleeve
tip
tip
sleeve
sleeve
tip
