23- Decor / Aufkleber
Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once. Peel off one corner of the
backing and cut off with scissors. Arrange sticker on model and when satisfied adhere the corner without backing.
Carefully peel back the rest of the backing while at the same time adhering the rest of the sticker.
Try not to make air bubbles, if there are some, carefully puncture sticker (center of bubble) but not model surface with the tip of the
knife or sharp pin and squeeze out the air. At curves stretch sticker and apply a little heat so that no ceases occur. Cut off the excess
that is produced.
WARNING: Please do not clean your model with pure alcohol or strong solvent, only use liquid soap with water or use glass cleaner
to clean on surface of your model to keep the colour not fade.
All details are subject to change without notice !
24- Balance / Schwerpunkt
Note: Adjust the location of the
battery pack to achieve this C.G
location.
25- Control surface / Ruderausschlage
RUDDER / SEITENRUDER
IMPORTANT: Flying your model at these throws will provide you with the greatest chance for successful first flights. If, after you have
become accustomed to the way the Yak flies, you would like to change the throws to suit your taste that is fine. However, too much
control throw could make the model difficult to control, so remember, "more is not always better".
Sticker
CHAMPION
A E R O S P A C E
POWERED BY
LYCOMING
TEXTRON
4-1/4"(107 mm)
AILERON / QUERRUDER
1-3/16"(30) mm
1-3/16"(30) mm
Technische Anderungen und Irrtumer vorbehalten !
DO NOT try to fly an out-of-balance model !
Wing center section
ELEVATOR / HOHENRUDER
N621TW
Sticker
(A + or - 5mm is fine)
1/4" (6mm)
1/4" (6mm)
25/64"(10mm)
25/64"(10mm)
