EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v6.46 or the latest stable version, to ensure compliance with local authority regulations!
It is the end users responsibility to follow local country regulations, including operation within legal frequency channels, output  power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be installed according to instructions.
This Quick Guide covers models: RBLtAP-2HnD (LtAP), RBLtAP-2HnD&R11e-LTE (LtAP LTE kit), RBLtAP-2HnD&R11e-4G (LtAP 4G kit), RBLtAP-2HnD&R11e-
LTE6 (LtAP LTE6 kit).
This is a wireless network device. You can find the product model name on the case label (ID).
Please visit the user manual page on
Technical specifications, brochures, and more info about products at
Configuration manual for software in your language with additional information can be found
If you need help with configuration, please seek a
This Device accepts input of 24V DC, 1.2 A power adapter, which is provided in the original packaging of this device. Alternatively, it's possible to
use a
PoE injector together with the power source in range 12-30 V (direct current) or an Automotive DC port together with a power source of 12-30 V (direct
current).
First steps:
Unscrew two screws and remove cover;
Connect your Internet cable to the Ethernet port (this is optional if using LTE as the primary connection);
Insert the SIM card into the SIM 2 slot (middle);
Connect GPS antenna (optional);
Connect to the power source;
Set your computer IP configuration to automatic (DHCP);
From your computer connect to the wireless network;
Open the
https://192.168.88.1
User name:
admin
, and there is no password;
Use the check for update option to upgrade the device to the latest version. You must have an active SIM card with available data;
The device will reboot;
Connect again and in the
QuickSet
Secure your device and set a strong password;
The
LtAP
device comes without a modem, install it before inserting a SIM card.
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the
correct hardware and configuration or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
Exposure to Radio Frequency Radiation:
uncontrolled environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general
public.
Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.
BG - Български. Бързо ръководство:
Това устройство трябва да бъде надстроено до RouterOS v6.46 или най-новата стабилна версия, за да се гарантира спазването на местните
наредби!
Крайните потребители са отговорни да спазват местните разпоредби, включително работа в рамките на законни честотни канали, изходна
мощност, изисквания за окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства MikroTik трябва да бъдат
инсталирани съгласно инструкциите.
Това кратко ръководство обхваща модели: RBLtAP-2HnD (LtAP), RBLtAP-2HnD&R11e-LTE (LtAP LTE kit), RBLtAP-2HnD&R11e-4G (LtAP 4G kit), RBLtAP-
2HnD&R11e-LTE6 (LtAP LTE6 kit).
Това е устройство за безжична мрежа. Можете да намерите името на модела на продукта на етикета на регистъра (ID).
Моля, посетете страницата с ръководството за потребителя на
QR кода с мобилния си телефон.
Технически спецификации, брошури и повече информация за продуктите
Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на
https://mt.lv/um
 for the full up to date user manual. Or scan the QR code with your mobile phone.
consultant https://mikrotik.com/consultants
in your web browser;
menu set your country, to apply country regulation settings;
This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

https://mikrotik.com/products
at https://mt.lv/help
https://mt.lv/um-bg
 за пълното актуализирано ръководство за употреба.
на https://mikrotik.com/products

Или сканирайте

https://mt.lv/help-bg
